temperature and humidity chamberEIE Humidity Oven confirming to standard specification is specially designed for climatic & du
temperature and humidity chamber
Construction Details :
Chamber : Triple walled
Interior : Polished Stainless Steel
Exterior : Heavy Gauge G.I.
Mobility : On caster Wheels
Insulation : Superior-thermo fiber board / PUF Insulation
Inner-Door : Full view glass with aluminum frame
Outer-Door : Of massive construction having seals against atmospheric infiltration by rubber gasket
Shelves : Fabricated precisely to offer minimum resistance to air circulation
Finished : With attractive and durable powder coated paint in pleasant shade
Control Accessories :
Circulation : Forced air circulation for uniform temperature by suction blower fitted with turbo F.H.P. Motor
Front Panel : Mains rocker switch, Cooling / Heating rocker switch, Micro - Controller, Ampere Meter, toggle switches for high & low position of heater fuse.
Illumination : With fluorescent light when door opens
Temperature Specifications :
Range : 10 degree centigrade to 60 degree centigrade
Accuracy : +/- 1 Degree centigrade or better
Controller : Micro-Controller PID Type
Display : Digital LED
Sensor : Pt - 100
Humidity Specifications :
Method : Steam injected humidity derived by RH Controller
Range : 40% TO 95% Rh
Accuracy : +/- 3 % Rh
Heating Accessories :
Tubular finned type heaters for dry temperature and relative Humidity
Refrigeration :
Compressor : Hermetically sealed of Kirlosker Make or equivalent
Optional Attachments at additional costs :
1) Hygrometer for direct Rh indication
2) Voltage stabilizer of suitable capacity
3) Lux-Meter for photo stability
Optional Wireless Communication :
1) Mode of controlling through PLC & HMI
2) USB Cable for seamless integration between PC (Personal Computer) & Humidity oven
3) Wireless communication with the help of RF Converter
4) Online data logging and editting (User can log, modify, and control the data from any corner of the world)
CHAMBER SIZE (CM) |
CU.FT |
KW |
SHALVES |
INNER S.S OUTER G.I.
(IS ) |
INNER /OUTER S.S 304
( CS ) |
INNER S.S.316-OUTER S.S.304 ( GMP)
( G ) |
FOR CEMENT TEST INNER S.S. + OUTER G.I. ( CT ) |
H X W X D |
|
` |
` |
` |
` |
||
A. 45 X 45 X 45 |
3 |
1.50 |
2 |
82600 |
107250 |
111800 |
85850 |
B. 70 X 50 X 50 |
6 |
2.00 |
3 |
91100 |
124750 |
131300 |
95300 |
C. 60 X 60 X 60 |
6 |
2.25 |
3 |
95350 |
128750 |
136000 |
105350 |
D. 90 X 60 X 60 |
9 |
2.25 |
3 |
99400 |
173150 |
145300 |
110300 |
E. 125 X 60 X 60 |
12 |
2.75 |
4 |
161800 |
224200 |
235400 |
161800 |
ESSENTIAL ACCESSORIES AT EXTRA COST
DESCRIPTION |
` |
|
A. 10 Ltr. capacity aspirator bottle(PP) for storage of DM/RO water and to serve as input water source for the water tank/ Steam boiler of Oven |
2500 |
B. Silicon rubber tubing - 3 meters for water supply from reservoir to Boiler |
750 |
OPTIONAL ACCESSORIES
DESCRIPTION |
` |
A.Digital Controller with standard PC software & connectivity. |
30000 |
|
B. Additional high temperature safety system to cut-off all heaters with audio-visual alarm ensuring temp. within chamber doesn't exceed +70°C |
5000 |
