Metal Sheet and Coil Slitting and Rewinding Machine, Galvanized Steel Coil Slitting Line for Sale
US$ 20,000 - 40,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
bluesteel
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo/shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Slitter Rewinder Machine, Metal Steel Coil Slitting and Rewinding MachineUS$ 20,000 - 40,000MOQ: 1 Set -
Hot Roll Metal Slitting Machine Line With Decoiler and RecoilerUS$ 50,000 - 150,000MOQ: 1 Set
-
Used Steel Coil Slitting MachineUS$ 50,000 - 150,000MOQ: 1 Set
-
Galvanized Slitting Line Machine / Steel Coil Cold Roll Sheet Slitting Machine With High SpeedUS$ 20,000 - 40,000MOQ: 1 Set
-
Automatic Steel Coil Slitting Line With Slitter Machine and Recoiler / Construction Use Machinery For SaleUS$ 20,000 - 40,000MOQ: 1 Set
Condition
New
Place of Origin
Zhejiang, China
Brand Name
bluesteel
Model Number
slitting line
Voltage
380V 3phase 50hz
Rated Power
300kw
Dimension(L*W*H)
36*2.2*2.2M
Weight
50000kgs
Warranty
14months
After-sales Service Provided
Engineers available to service machinery overseas
Workflow of slitting line:
machine photos:
hydraulic uncoiler system hydraulic uncoiler system
loop slitting
recoiler stacker
whole view whole view
slittine part slitting part
Material of processible coiled plate: apply for carbon steel plate δ b≤380Mpa;
- 1. Thickness of coiled plate: δ=0.3—3mm;
- 2. Width of coiled plate: slitting 1800mm;
- 3. Precision of slitting: width tolerance: ±0.1mm;
- 4. Slitting speed: 0—50m/min(adjustable) ;
- 5. Loading capacity of uncoiler: 20T;
- 6. Coil I.D: 508mm—610mm; two-step pattern
- 7. Coil O.D: ≤1600mm;
- 8. Main shaft diameter of slitter: 240mm; material 40Cr;
- 9. Width of slitting steel: ≥35mm;
- 10. Slitting blade: D240×D350×15; 42 pcs, cutting strips: 20 pcs;
- 11. Material of slitting blade: 6CrW2Si;
- 12. Hardness of blade: HRC58—60;
- 13. Recoiler I.D: D508mm, loading capacity: 20T
