Antenna Manufacturer Aluminium 2.4GHz 16dBi High Gain Wifi Outdoor Yagi Antenna

Name: Antenna Manufacturer Aluminium 2.4GHz 16dBi High Gain Wifi Outdoor Yagi Antenna
Brand: AMEISON
SKU: 126217367

Negotiable MOQ: 500 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

AMEISON

Model Number:

AMXY-2400-16

Shenzhen Ameison Communication Equipment Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen or HongKong

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name AMEISON

Model Number AMXY-2400-16

Specifications

High gain;Aluminum alloy framework;Full day working;Optimized dimension;Vertical or Horizontal Mounting way;Factory Price.

2.4 GHz 16 dBi Yagi Antenna

Factory price

Solid aluminium elements

Heavy-duty aluminium boom

Included Mounting kits

2400-2483MHz Directional Yagi Antenna

AMXY-2400-16

Feature:

High gain

Aluminum alloy framework

Full day working

Optimized dimension

Mounting way can be Vertical or Horizontal

Application:

2.4GHz WLAN system

Point-to-point,point-to-multipoint system

Wireless bridging,client termination antenna

AMXY-2400-16 Electrical Specifications
Frequency range(MHz)	2400-2483
Bandwidth(MHz)	83
Gain(dBi)	16
Element	16
Half-power beam width(°)	H:35 V:30
Front-to-back ratio(dB)	≥16
VSWR	≤1.5
Input Impedance(Ω)	50
Polarization	Horizontal or Vertical
Maximum input power(W)	100
Lightning protection	DC Ground
Input connector type	RP-SMA male or others
Mechanical Specifications
Dimensions(mm)	5207044
Cable length(m)	1
Antenna weight(kg)	0.33
Operating temperature(°c)	-40~60
Rated Wind Velocity(m/s)	60
Clamp	U-shape
Mounting hardware(mm)	Φ35~Φ50
