Specifications
1. Short drying time, high efficiency2. Easy to operate, low labor intensity
3. Easy to clean
4. GMP
1. In the Tomato powder production line, YPG Pressure Spray Dryer is widely used for drying coffee paste to coffee powder.
Spray drying is a method of producing a dry powder from a liquid or slurry by rapidly drying with a hot gas. This is the preferred method of drying of many thermally-sensitive materials such as foods and pharmaceuticals. A consistent particle size distribution is a reason for spray drying some industrial products such as catalysts. Air is the heated drying medium; however, if the liquid is a flammable solvent such as ethanol or the product is oxygen-sensitive then nitrogen is used
All spray dryers use some type of atomizer or spray nozzle to disperse the liquid or slurry into a controlled drop size spray. The most common of these are rotary disks and single-fluid high pressure swirl nozzles. Alternatively, for some applications two-fluid or ultrasonic nozzles are used. Depending on the process needs, drop sizes from 10 to 500 µm can be achieved with the appropriate choices. The most common applications are in the 100 to 200 µm diameter range. The dry powder is often free-flowing
Spray Drying is still the most economical method of evaporation to reduce a liquid feed to solid powder particles. Powder remaining one of the most versatile methods of preservation and cost effective in both storage and transportation of finished goods.
Following is a PID diagram of tomato paste spray drying:
And following are pictures of our big pressure spray dryer that made in client’s factory:
4. Other application of YPG Pressure Spray Dryer:
Foodstuff industry: Amino acid and similar substance, flavoring, protein, starch, dairy products, instant coffee, fish powder, meat powder, tomato paste and so on.
Pharmaceutical Industry: Chinese patent medicine, agrochemical, antibiotics, medical drinking agent and so on.
Chemical industry: Organic catalyst, resin, synthetic washing powder, thiamin, dyestuff, intermediate of dyestuff, intermediate of dyestuff, white carbon black, graphite, ammonium phosphate and so on.
Ceramic industry: Magnesium oxide, kaolin, metallic oxide, dolomite and so on.
5. Features of YPG Pressure Spray Dryer:
- The machine has high efficiency to collect dust
- Without the phenomenon of adhering wall
- Energy saving and high efficiency
- Particularly it is suitable for thermal sensitive material
- Short drying time
6. Technical parameters of YPG Pressure Spray Dryer
|
Model Item |
YPG-25 |
YPG-50 |
YPG-100 |
YPG-150 |
YPG-200 |
YPG-300 |
YPG-500 |
YPG-1000~2000 |
||
Water evaporation(kg/h) |
25 |
50 |
100 |
150 |
200 |
300 |
500 |
According to actual situation |
||
Diaphragm pump |
Power (Kw) |
0.35 |
4 |
7.5 |
11 |
15 |
22 |
30 |
||
Pressure (Mpa) |
It can be regulated from 0.6-5. In general, it is 1-3 |
According to actual situation |
||||||||
Heating source |
Electricity |
Electricity + steam |
Hot air furnace |
|||||||
Diameter of tower (mm) |
1300 |
1800 |
2400 |
2600 |
2800 |
3200 |
3800 |
According to actual situation |
||
Height (mm) |
7800 |
9200 |
11600 |
14000 |
15300 |
17100 |
19000 |
|||
Following is pictures of one small pressure spray dryer that manufactured in our workshop and installation site in client’s factory:
