Help CenterMining Rubber Sheath 95mm2 150mm2 Copper Conductor Cable
Related Products
-
Double Braid Shield Cable MCP/MCPT 4x185mm2 Mining CableUS$ 0.9 - 15MOQ: 500 Meters -
Heat Resisitance 450/700v Pvc Insulated Rubber CableUS$ 0.9 - 15MOQ: 500 Meters
-
Hot Sale H07rn-f Aluminium Almg 18 Core 2.5 mm Power Cable RubbeUS$ 0.9 - 15MOQ: 500 Meters
-
Flexible Copper Ho7rf-f/ho5vv-f 2x1.5 Cable Rubber CableUS$ 0.9 - 15MOQ: 500 Meters
-
RTI-1 or RTI-2-CL Flexible 450/750v 4 Core Rubber Cable 16mmUS$ 0.9 - 15MOQ: 500 Meters
mining rubber sheath 95mm2 150mm2 copper conductor cable Description:
Standards
BS7919, CENELEC HD22.4 S4
Conductor
Class 5 flexible plain copper
to BS EN 60228:2005 (previously BS6360)
Insulation
EPR (Ethylene Propylene Rubber) Type EI4 to BS7655
Sheath
PCP (Polychloroprene) Type EM2 to BS7655
mining rubber sheath 95mm2 150mm2 copper conductor cable
Voltage Rating 450/750V
Temperature Rating
Conductor operating temperature
-30°C to +60°C (85°C max)
Minimum Bending Radius
Up to 25mm2: 6 x overall diameter
Above 25mm2: 8 x overall diameter
Core Identification
1 Core: Black
2 Cores: Blue, Brown
3 Cores: Green/Yellow, Blue, Brown
4 Cores: Green/Yellow, Brown, Black, Grey
5 Cores: Green/Yellow, Blue, Brown, Black, Grey
6 Cores and above: Black with White numerals, Green/Yellow
mining rubber sheath 95mm2 150mm2 copper conductor cable parameter list:
|
Nominal Section-Area of Conductor(mm2) |
Structure of Conductor | Nominal Thik-ness of Sheath (mm) | Overall Diameter | Max. Conductor Resistance at 20º C (Ω /km) | Approx. Weight (kg/km) | ||
| Core no. /Dia. (no. /mm) | Min. | Max. | YH | YHF | |||
| 10 | 322/0.20 | 1.8 | 7.5 | 9.7 | 1.91 | 146 | 153.51 |
| 16 | 513/0.20 | 2.0 | 9.2 | 11.5 | 1.16 | 218.9 | 230.44 |
| 25 | 798/0.20 | 2.0 | 10.5 | 13.0 | 0.758 | 316.6 | 331.15 |
| 35 | 1121/0.20 | 2.0 | 11.5 | 14.5 | 0.536 | 426 | 439.87 |
| 50 | 1596/0.20 | 2.2 | 13.5 | 17.0 | 0.379 | 592.47 | 610.55 |
| 70 | 2214/0.20 | 2.4 | 15.0 | 19.5 | 0.268 | 790 | 817.52 |
| 95 | 2997/0.20 | 2.6 | 17.0 | 22.0 | 0.198 | 1066.17 | 1102.97 |
| 120 | 1702/0.30 | 2.8 | 19.0 | 24.0 | 0.161 | 1348.25 | 1392.55 |
| 150 | 2135/0.30 | 3.0 | 21.0 | 27.0 | 0.128 | 1648.5 | 1698.72 |
| 185 | 1443/0.40 | 3.2 | 22.0 | 29.0 | 0.106 | 1983.8 | 2020.74 |
mining rubber sheath 95mm2 150mm2 copper conductor cable Packaging:
Material:
Rolls without drum / wooden drum / steel wooden drum (fumigation)
Cable length in each drum: 500m/1000m or as per actual cable length requirements.
Drum size:
As per cable length and container size
*In order to quote you accurate price, kindly tell us your needed cable length quantity. Larger quantity, more discount benefit ready for you!
Shipping:
Port: Tianjin, Qingdao, or other ports as per your requirements.
Sea freight and insurance fee:
FOB/C&F/CIF quotation are all available.
*For some countries such as Africa countries, middle east countries, our sea freight quotation is much cheaper than clients get from local shipping agency.
about the seriveice of mining rubber sheath 95mm2 150mm2 copper conductor cable
1)Quality first, customer first, safety first
2)Better service, faster delivery
3)Equal and mutual benefit
4)Honesty and profession
Zhengzhou Hongliang Cable Co.,ltd is one of the branch of Huadong Cable Group ,and also is biggest professional import and export trade company in China.
The plant was founded in 1998, occupied 50,000 square meters,with advanced equipments of 20 sets production lines and 25 sets testing machines,Annual production capacity is more than 12 million kilometers.
Our international branch is located in Zhengzhou city,which is well-known for convenient transportation . We mainly produce and export all aluminum conductor(AAC), aluminum conductor steel reinforced(ACSR), all aluminum alloy conductor(AAAC), overhead Aerial bundled ABC cable,1-66kV power cables(including XLPE insulated cables, PVC insulated cables, SWA/STA armored cables).(XLPE/PVC insulated ABC cable),control cables, welding cables, rubber cables ,mining cables and electrical wires(PVC sheathed flexible cable).
Our products honoured I S O 9 0 0 1:2 0 0 2 and CCC,PCCC,SGS,BV certificates. We strictly according to GB,IEC,BS,ICEA, ASTM, DIN, VED, JIS standards to manufacture the products, and also we can design and produce according to customers' requirements.
The question about mining rubber sheath 95mm2 150mm2 copper conductor cable
Q 1: I didn’t find my needed cable in this page.
Answer: Dear Friend, Kindly check our catalog. Also, we supply customization service. So, contact us ! :)
Q 2: What’s your Minimum Order Quantity?
Answer: Normally, 100m for small wires. 200m for unarmoured cable. 500m for armoured cable. 1000m for power cable
above 69kV.
Q 3: When can i get the price and what’s the validity?
Answer: For standard types and small orders, it take less than 24 hours. For big quantity and plenty types, it takes less
than 48 hours. Validity is 7 days or as per LME price for tenders and big orders.
Q 4: What’s your payment terms?
Answer: By T/T 30% in advance ; Balance 70% before shipment. Or LC at sight. Now you can pay through Alibaba
company to our Alibaba sub-account.
Q 5: What’s your delivery time?
Answer: It depends on whether we just has the stock for your type. Or, it takes about 10 - 30 days for normal orders.
Q 6: How is your quality guarantee?
Answer: It will be stated along with our quotation sheet.
Q 7: What’s your package method?
Answer: Usually, it’s cable reel for wires. Wooden drums for small size cables and steel drums for big size cables.
Anyway, all are exporting package to assure no damage in the transportation process.
