Linear Actuator for Solar Tracking System
US$ 20 - 30
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Anhui, China
Brand Name:
RISESAT
Model Number:
RS450
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Linear Actuator With HALL Sensor RS-DH,accurate PositioningUS$ 25 - 35MOQ: 100 Pieces -
Lifting Column for Height Adjustable DeskUS$ 199 - 210MOQ: 10 Pieces
-
Dual Drive Actuator, Dual Linear ActuatorUS$ 20 - 30MOQ: 100 Pieces
-
Dual Drive Actuator for Bed Lifting SystemUS$ 20 - 30MOQ: 100 Pieces
-
12V Mini Linear Actuator 1500NUS$ 20 - 35MOQ: 100 Pieces
Place of Origin
Anhui, China
Brand Name
RISESAT
Model Number
RS450
Specifications
Solar Actuator, linear actuator for solar tracking system,,1.waterpr,
2.low noise.
3.for Solar Tracker system
Linear Actuator for solar panel system
RS450 Model
Feature / Benefits:
Adjustable stroke
Reed sensor
Acme screw
Self-locking Water & dust resistant Enhanced antirust quality
High performance & service life
High precision
Heavy duty bracket and static load capacity
Option Stroke length:
18"/ 24"/ 36" (inch)
Voltage:24 /36 VDC
Sensor type : Reed
Drive screw : Acme
Rating Operating temperature: from -30°C to 50°C
OPTIONAL: RUBBER SLEEVE
Spec. |
|||
Actuator Type |
Rod type |
||
Stroke length |
36" |
24" |
18" |
Optimal stroke |
30"~34" |
20"~22" |
14"~16" |
Static Load |
11,760 N |
||
Load capacity |
4,410N |
|
|
Dynamic load |
7,840 N |
||
Speed(Non-load) |
3.2mm/sec. |
|
|
Resolution |
1.89 pulse/mm |
||
Input Voltage |
36VDC |
||
Load current |
≤2.5A |
|
|
Duty cycle |
20% |
|
