Help CenterYM85 Ultrasonic Oversee Edge and Rewinding Machine
Related Products
Application:
Use ultrasonic elements oversew the edges of several rolls non-woven together. So that the width of one roll will be increase to several rolls and not need change the width of produce equipment can process more wider non-woven products which is larger than original. Thereby developing the use of original products.
Features :
1. Key type air expanding shaft for the unwinding and rewinding.
2. Magnetic brake for unwinding , semi-automatic tension controller.
3 .Photoelectric edge position controller
4.Ultrasonic envelop edge, the width can be adjustable.
5.Friction cylinder impact rewinding.
6.Steel plate structure, install shell, plastic sprayed on the surface.
Main technical
Item |
Parameters |
|
Width of machine rollermm |
2600 |
|
Diameter of unwinding and rewindingmm |
700 |
|
Designed speedm/min |
~22 |
|
Power supplykw |
20 |
25 |
Dimension(cm) |
|
|
Weightkg |
3000 |
|
