Specifications
MPPT Tracer Solar Charger Controller Regulator with LCD Display remote meter.Advanced MPPT technology.
LCD remote meter.
MPPT Tracer Solar Charger Controller Regulator with LCD Display remote meter
Technical Specifications
Description |
Parameter |
Norminal system voltage |
12VDC or 24VDC |
Rated battery current |
10A |
Battery voltage range |
9 – 36V |
Max. solar input voltage |
TRACER-1206 60VDC TRACER-1210 100VDC TRACER-1215 150VDC |
Max. PV input power |
12V/120W 24V/240W |
Self-consumption |
≤16mA |
RJ45 connection |
8pin |
Load surge protect |
35A |
MPPT Solar Charge Controller Technology:
The TRACER utilizes Maximum Power Point Tracking technology to extract maximum power from the solar module.
The tracking algorithm is fully automatic and does not require user adjustment, TRACER technology will track the array maximum power point voltage (Vmp) as it varies with weather conditions, ensuring that maximum power is harvested from the array through the course of the day.
LCD Remote Meter used for EP MPPT Solar Controller
Features
Remote digital display for the MPPT Solar Charge Controller.
Ideal for monitoring and display current solar system status.
Displays both solar voltage and battery voltage as well as charging current and load current.
Shows Amp-Hour and Watt-Hour charge accumulation as well as percentage the batteries are charged.
Easy to use and program and is ideal for a quick system check.
Wall mounting board, can be mounted in or on the wall.
Full Digital Display
Displays Voltage, Current, Amp-Hours, Watt-Hours and Percentage Charge
Suitable for both 12V and 24V Systems
Temperature Display
Easy to Use and Set-Up
Full Installation Instructions Included.
Specifications:
Rated voltage: 12V, min voltage(suggest): 8.0V.
Strong backlight on: <23mA,
Low backlight on: <20mA
Backlight and LED indicator off: <17mA
Operation temperature: -40C ~ +60C
LCD operation temperature: -10C ~ +40C
Humidity: 0-100%
Communication cable: RJ45(8PIN)
