Specifications
1. highly automatic2. good quality of cutting
3. high accuracy of shearing
4. high producing efficiency
5. factory
Asvantages of automatic high-efficiency coil up-ender for 25T:
1. highly automatic
2. good quality of cutting
3. high accuracy of shearing
4. high producing efficiency
I. Technical Parameter of automatic high-efficiency coil up-ender for 25T:
a.Max Coil width: 1500-2000mm
b.Max Coil diameter: 1500-2000mm
c.Capacity: 25T
d.Rated power: 11kw
e.Machine weight:about 5T
f. The diameter of hydraulic oil cylinder: φ220mmx2
g. Pressure of hydraulic system: 0-16Mpa
h. Gear pump model: CBT-F60
II. Devices of automatic high-efficiency coil up-ender for 25T:
1). Adopt the independent hydraulic and electrical system with the hydraulic pressure and control unit insert.
2). The valve uses DC24V, the electrical control adopts 24V pressure.
III. Payment term of automatic high-efficiency coil up-ender for 25T:
1).Delivery time: 30 days after we receiving 30% deposit.
2). Payment: T/T, 30% as advance, 70% T/T before the shipment.
The pictures of automatic high-efficiency coil up-ender for 25T:
Application:
