0.6/1kv Cu/xlpe/swa/pvc Power Cable 4 Core 240mm Xlpe Armoured Cable Wire

Name: 0.6/1kv Cu/xlpe/swa/pvc Power Cable 4 Core 240mm Xlpe Armoured Cable Wire
Brand: CHANGFENG
SKU: 126665787

US$ 0.5 - 0.5 MOQ: 150 Feet

Key Specifications

Place of Origin:

Hebei, China

Brand Name:

CHANGFENG

Model Number:

XLPE Power Cable

Changfeng Wire & Cable Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Hebei, China

Brand Name CHANGFENG

Model Number XLPE Power Cable

Insulation Material XLPE

Type Low Voltage

Application Underground

Conductor Material Copper

Jacket PVC

0.6/1kv cu/xlpe/swa/pvc power cable 4 core 240mm xlpe armoured cable wire

Conductor: Compacted Stranded Copper conductor, Class 2 as per IEC 60228

Conductor Screen: Semi-conductor (MV only)

Insulation: XLPE

Insulation Screen: Semi-conductor (MV only)

Separate Screen: Copper Tape or Copper Wire & Tape

Wrapping Tape : Non-woven

Inner Covering: Extruded PVC (Armored only)

Armour : Steel Wire, or Steel Tape, or Aluminium Wire optional (Armored only)

Sheath: PVC/ST3 to IEC 60502, black, PE, Flame Retardant PVC, LSOH

Note: Insulation color as per standards or customer requirement

Specifications

YJV	Copper Conductor, XLPE Insulated, PVC Sheathed Power Cable	For laying indoors and outdoors. Able to bear certain traction during installation, but not external mechanical forces. Laying single core cable in magnetic ducts is not allowed.
YJLV	Al. Conductor, XLPE Insulated, PVC Sheathed Power Cable
YJY	Copper Conductor, XLPE Insulated, PE Sheathed Power Cable	For laying indoors and outdoors. Able to bear certain traction during installation, but not external mechanical forces. Laying single core cable in magnetic ducts is not allowed.
YJLY	Al. Conductor, XLPE Insulated, PE Sheathed Power Cable
YJV22	XLPE Insulated,Steel Tape Armored,PVC Sheathed Power Cable	Suitable for burying in ground, Able to bear external mechanical forces but large pulling forces.
YJLV22	Al. Insulated,Steel Tape Armored,PVC Sheathed Power Cable
YJV32	Copper Conductor, XLPE Insulated, Fine Steel Wire Armored,PVC Sheathed Power Cable	Apply to shafts,water and soil,able to bear the larger positive pressure.
YJLV32	Al.Conductor, XLPE Insulated, Fine Steel Wire Armored,PVC Sheathed Power Cable
YJV42	Copper Conductor, XLPE Insulated,Thick Steel Wire Armored,PVC Sheathed Power Cable	For laying in shaft, water underground and large diference of level, able to bear external mechanical pressure and moderate pulling force.
YJLV42	Al.Conductor, XLPE Insulated,Thick Steel Wire Armored,PVC Sheathed Power Cable
