Specifications
Designed with longer coils that extend beyond the end of the struts. Plastic cones screw onto the projections to provide a posit2-strut coil tie
The 2-Strut Coil Tie is an effective way to lift and handle your thin wall concrete element.
The coil tie forming system is a medium to heavy duty forming system, consisting
Of 3/4" form-ply using lumber stud and wales.
Panels can be prefabricated or job built to accommodate a variety of forming needs.
Coil ties can be used with or without cones or combines with coil rod to make and adjustable tie.
The coil tie forming system allows for a larger tie spacing than the Snap-Tie system,is including Coil ties, coil rod, nuts, washers, plywood,
The Two Strut Coil Tie is fabricated with two struts and two self-cleaning, fast threading coils and is available in a broad range of sizes and safe working loads. The versatile tie is used with Coil Bolts or Coil Rod to handle the many forming variations encountered. The Two Strut Coil Tie siavailable in 1/2" to 1" diameters in standard and heavy types. Safe working load is based on an approximate 2:1 safety factor. Note: If electro-plating of coil ties is required, special procedures may be necessary to prevent hydrogen embrittlement effects. Specify when placing order.
Specifications
coil tie
1.plated coil ties are avaliable.
2.length:4" to 48"
3.two strut,four strut
4.standard and heavy
Coil ties are avaliable 4" througth 48".
Order request:
1.name 2.length 3.quantity
