With HYSJ65/28 extruder 7-16mm medical PVC soft pipe Line
Consist of:
1. Single screw extruder: SJ65/28 1 set
2. Die head 1 set
3. Cooling water tank 1 set
4. Haul-off unit 1 set
5. Cutter 1 set
6. Transmit & collect system 1 set
1,65 Extruder
a: Screw:
—Material: high strength nitride alloy steel(9Cr18MoALA),high precision special screw
—Diameter:65MM
—L/D: 28:1
—Screw Length:1820mm
— Compression ratio:3.0
— Surface treatment: nitriding, mirror polished
— Nitriding depth:0.9-1.2mm
— Nitrided surface hardness: HRC55—HRC58
— Brittle: no more than grade two
—Screw work surface roughness requirement is not lower than Ra0.8 um
—Surface treatment: Mirror Polishing
b: Barrel
—Material: high strength nitride alloy steel (38CrMoALA)
—Inner Surface Treatment: nitriding, polishing
—Heat Control:7 zones
—Heat Removal:4 zones
—Cooling system: Multi-blades high efficiency cooling fan with low noise
—Wind Cover’s Material: SUS304 stainless steel
C:Gear box
— Hight Precision special reducer
— Materials: alloy steel (40CrMnMo)
— Gear: helical gear
— Shaft: 40 Cr
d:Control system
—Germany's Siemens PLC programming control
—Siemens PID temperature control module
—Siemens 10.4 "human-machine interface
— Temperature alarm, in the software implementation of upper and lower limits
— Thermocouple module has break line disconnection alarm, temperature alarm functions
—Japan's Yaskawa AC Inverter Drive
—Guangdong JiangSheng motor
—Drive power:22 KW
—Taiwan Yangming solid state relay
—High efficiency Heater
2. Head & Die
—Stainless steel single tubing head
—Stainless steel single tubing Die
3. Stainless steel cooling water tank
— Length:4m
— Body:thickness: 2MM, formed by welded and bended SUS304 stainless steel
—Vacuum length:800mm
— Toughened glass cover:10mm
— Water-loop vacuum pump, power: 1.1KW
— Stainless steel reservoir
—High grade PU universal trundle
—All glass lid closed structure
—3D adjustable water tank frame
4. Medical grade haul-off unit
—High precision rolling rail guidance system
— Screw with adjustable center height & open/close
— High precision worm gear reducer
— Low inertia ribbed belt pully
— High precision worm gear reducer
— Siemens servo motor
— Siemens servo controller
— Drive power:400W*2
— Active length:400mm
— Active width:50mm
— Adjustable range:0~60m
5. Micro-Computer Intellectual Cutter
— Aluminum alloy rotatable knife arm of low-inertia
— A special cutter sheath with smooth incision
—Mitsubishi servo motor driver
— Mitsubishi servo controller
— Drive power:750KW
— Siemens man-machine interface
— Mitsubishi PLC controller
— Cutting length can be set up freely
— Cutting frequency automatic counting
— High grade PU universal trundle
6. Finished products transmit & collect system
— Medical grade transmitting belt
— Planetary gear
— Oriental motor
— Drive power:200w
— Active length:2000mm
Remarks:
1.This extrusion line adopts the maintenance-free motor and speed reducer drive straight league way, can effectively prevent the low efficiency of conventional belt transmission, great error in the transmission of revolution, belt and pulley of friction powder pollution clean workshop and so on defect;
2. This extrusion line from the mold to cut off the conveyor trough, where contact with the product are imported 304 stainless steel precision forming, tractor adopts Siemens servo motor control, ensure the long-term operation, drawing the stability of high speed and high precision low water tank with water ring type vacuum degree of vacuum forming way, ensure pipe roundness and accuracy;
3.1 year guarantee for machine damage except damage in material and workmanship
Our products and services range:
1. extruders in single or twin screw, parallel or conic
2. kinds of pipe production line, like rigid PVC, soft PVC, conduit, cable,PE water supplier pipes, PPR pipes....etc.
3. kinds of profile producton line, such as PVC windows production lines, PVC profile lines, PVC ceiling lines, PVC roof lines, WPC profile lines..etc
4. kinds of sheet, board production lines, such PVC foaming board/sheet production lines, PVC door production lines, WPC door production lines, WPC foaming board lines....etc.
5. kinds of granulating, pelletizing lines
6. all the auxiliary machine of above lines and spare parts, such as screw barrel, mixer, miller, crusher, cooling tower, cooler, shredder, inverter, molds...etc
7. all the techical data and tecknology of above machines
8. Wood and Plastic Composite decorational profiles and door, such as WPC ceiling, wallboard, floor board, deck board, blind, doors ....etc.
1. Owns more than 30 years in extrusion field
2. Introduction from German tech and experience for the design and making twin screw extruders. And leaded by Germany experts Mr. Youcef and Mr. Elben for the long time
3. Designed and produced twin conical screw extruder, twin parallel screw extruder, and transfer the technology to the biggest gears factory in India
4. Own a high professional design team
5. A base combined with designing, making, studying ....etc. in extrusion industrial.
6. Our aim is to learn advanced technology, make the best suitable machine, best efficient machine and lines.
How is HYPET doing in the market?
l More than 30 years experience in the extrusion filed
l Extrusion machinery factory located in wuhan , central of china
l We focus on tailor made plan with exclusivity to each customer
l We have vast resources which can be integrated as whole package service
l We have accumulated vast sale network all over the world
What does HYPET offer to you ?
l Tailor designing for your factory lay out
l Tailor designing for water, electric ,and gas chart
l Tailor made processing technology
l Tailor made production line
l Package pre & after services
l On site installation and training
l Free marketing consultation
Why you should corporate with HYPET ?
l More than 30 years experience in extrusion, with years of international technical exchange experience;
l A team of highly professional technical expert ensures you get the state of art technology;
l Eruo technology ,designing, and processing application for twin screw extruder;
l Optimized design for different material, based on vast successful practical experience;
l HYPET set up separate laboratory with top equipment
l Extrusion performance and capacity proven by trial commissioning for each order
l Capable of providing on site technical training
l Unique design ,same line, suitable for various products
l Also provide various down stream and auxiliary machinery .
What are the HYPET services?
Each order tested before shipping and before payment;
Each order will meet the customer’s satisfaction before payment;
Deposit of Some machinery, if result not satisfied, can be refund;
A team of experience technical engineer can be sent for installation and training;
A standard of spare part will be also provide in each order.
