Paper Bursting Strength Tester

Paper Bursting Strength Tester thumbnail-1
Paper Bursting Strength Tester photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
HST or OEM
Model Number:
PN-BSM160
Contact Supplier Request Quote Chat Now
Jinan Hensgrand Instrument Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name HST or OEM
Model Number PN-BSM160
Power Electronic
Usage Strength Testing Machine

Specifications

Paper Bursting Strength Tester
1.No sample prompts function.
2.Overrange alarm function.
3.Adopt ARM processor, high speed.

Paper Bursting Strength Tester



Introduction

PN-BSM160 Type Busting Tester is available to test a variety of paper. These models can also be fitted with a device to measure the deflection of the sample prior to burst.

PN-BSM160 Bursting Strength Tester has abundant functions, such as, parameter testing, parametric transformation, parameter adjusting, parameter memory and parameter print. All are in accordance with related national standards. PN-BSM160 Bursting Strength Tester has data processing function which can directly output result of data statistics with convenient operation, easy regulation and stable performance



Application

It is applicable to paper having bursting strengths within the range 70kPa to 1400kPa. It is not intended to be used for the components (such as fluting medium or linerboard) of a combined board, for which the method given in ISO 2759 is more suitable.



Principle

A test piece placed over a circular elastic diaphragm, it is rigidly clamped at the periphery but free to bulge with the diaphragm. Hydraulic fluid is pumped at a constant rate, and bulged the diaphragm until the test piece ruptures. The bursting strength of the test piece is the maximum value of the applied hydraulic pressure.



Features

1. No sample prompts function.

2. Overrange alarm function.

3. Adopt ARM processor, high speed.

4. Using 24 precision AD converter (resolution up to 1 / 10,000,000) and high precision weighing sensor ,high accuracy.

5. Real-time display force value and deformance curve.

6.  Bulit-in printer

7. Unit switch among kPa,kgf/cm2,lbf/in2

8. Language switch between Chinese and English.

9. PC Software to transfer data to Excel.



Specification

1. Power supply:  AC220V±10%  2A  50Hz;

2. Error of indication:  ±0.5%;

3. Resolution:  0.1 kPa;

4. Measuring range: (70 ~ 1400)kPa;

5. Pumping rate: (95±5)mL/min

6. Clamping force:  ≤1200 kPa(Adjustable)

7. Air compressor: Rated pressure(0.6~0.7)MPa Exhaust volume(0.02~0.3)m3/min(No standard)

8. Diaphagm:  Bulge height(9±0.2)mm, pressure range(30±5)kPa

9. System sealing:  Within 1min pressure drop<10%FS

10. Display:  128 × 64 dot matrix LCD

11. Printer:  Thermal printer

12. Data Output::  RS232(Standard) / USB(Optinal)

13. Working condition: Indoor temp.(20  ±  10 )°C  relative humidity < 85%

14. Dimension:  (535 × 365 × 585) mm(L×W×H)

15. Net Weight:  About 68 kg
