Specifications
1.usage:wood tensile,compression,bend test2.digital table display
3.double column structure
4.with CE
10 kN digital display wood board universal testing machine
Application:
This machine made for the wood manufacturing and quality supervision station. Can do the following test: bone strength, surface bone strength, tensile strength, bending strength, modulus of elasticity test, screw griping test and shear test of of MDF,shaving board, plywood, core-board.
Technical parameter:
Model |
MWD-10 |
Max testing force (kN) |
10 |
Overload protection |
More than full range 2%-5% |
Tensile space (mm) |
0-700 |
Effective testing width (mm) |
400 |
Testing force range |
2%~100%FS |
Testng force accuracy |
≤±1% |
Load speed(mm/min) |
0.05mm/mim-500mm/min |
Relative error of displacement indicating |
≤±1% |
Displacement resolution |
0.01mm or customized |
Power supply |
220V±10%,50Hz |
weight |
450kg |
