NB17 - NUUO SCB-C24 16 CHANNEL DIGITAL OUTPUT BOX

NB17 - NUUO SCB-C24 16 CHANNEL DIGITAL OUTPUT BOX thumbnail-1
NB17 - NUUO SCB-C24 16 CHANNEL DIGITAL OUTPUT BOX photo-1
US$ 272 - 340 MOQ: 10 Units
Key Specifications
Get Latest Price
Place of Origin:
Leicestershire, United Kingdom
Brand Name:
NUUO
Model Number:
SCB-C24
Contact Supplier Request Quote Chat Now
Digiteck Ltd
Payment & Shipping
Payment Methods:
Port of Shipment:
UK
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Leicestershire, United Kingdom
Brand Name NUUO
Model Number SCB-C24

Product Description



• The NUUO SCB-C24 16 Channel Digital Output Box is an I/O box to intermediate the communication between a surveillance server and multiple peripherals.
• It joins up all the major components in your surveillance network to deliver your prospective management and protection over your property.
• Easy-to-mount and flexible in communication, C24 will be the pivot in your surveillance network.
• Supports Wide Range of DC-In Voltages
• Supports ASCII and Modbus/RTU Protocols
• Digital Output Signal
• 3750 Vrms Isolation Protection
• Supports Dual Watchdog
• External Dip Switch
• Status LED for Each Channel
• DIN-Rail and Panel Mount Support
• Support Screw Terminal
• Protocol: ASCII and Modbus RTU
• Interface: RS-485 differential 2 half/duplex wires
• Speed: 1.2 to 115.2 Kbps auto-switching
• Data Format: Data Bit: 8
• Parity Check: None
• Stop Bit: 1
• Distance: Maximum 4000' (1200 m)
• Digital Output: 3750 Vrms (isolation)
• Power Supply Input Voltage: 10 to 30 VDC
• Maximum Output Voltage: 30 V
• Maximum Output Current: 100 mA
• Power Supply: Screw terminal or external DC adapter
• Power Consumption: 1.5 W
• Operating Temperature: 32 to 149°F (0 to 65°C)
• Storage Temperature: -4 to 149°F (-20 to 65°C)
• Humidity: 10 to 90%, non-condensing
• Connection Type: Screw terminal for maximum AWG# 12 to 30 wire
• LED Indicators: Status LED for power and all output channels
• Dimensions: 5.94 x 2.95 x 1.02" (151 x 75 x 26 mm)
• Weight: 13.93 oz (395 g)
• Includes External DC Power Adapter
