DIN,ASTM, JIS, EN H Shape Steel Beam, BS Standard High Quality H Beam

DIN,ASTM, JIS, EN H Shape Steel Beam, BS Standard High Quality H Beam thumbnail-1
DIN,ASTM, JIS, EN H Shape Steel Beam, BS Standard High Quality H Beam thumbnail-2
DIN,ASTM, JIS, EN H Shape Steel Beam, BS Standard High Quality H Beam thumbnail-3
DIN,ASTM, JIS, EN H Shape Steel Beam, BS Standard High Quality H Beam thumbnail-4
DIN,ASTM, JIS, EN H Shape Steel Beam, BS Standard High Quality H Beam photo-1
DIN,ASTM, JIS, EN H Shape Steel Beam, BS Standard High Quality H Beam photo-2
DIN,ASTM, JIS, EN H Shape Steel Beam, BS Standard High Quality H Beam photo-3
DIN,ASTM, JIS, EN H Shape Steel Beam, BS Standard High Quality H Beam photo-4
US$ 405 - 405 MOQ: 5 Tons
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Grade:
Q235B
Technique:
Hot Rolled
Contact Supplier Request Quote Chat Now
Hangzhou Mindfull Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Grade Q235B
Technique Hot Rolled
Thickness 4.5mm-34mm
Application Steel Structure
Length 6-12m
Flange Width 100mm-300mm
Flange Thickness 4.5mm-23mm
Web Width 100mm--300mm
Web Thickness 4.5-45mm
Brand Name TUS
Model Number Hot Rolled Prime Steel

Structural carbon steel h beam profile H iron beam (IPE,UPE,HEA,HEB)

 DIN,ASTM, JIS, EN H shape steel beam, BS Standard High Quality H BeamDIN,ASTM, JIS, EN H shape steel beam, BS Standard High Quality H BeamDIN,ASTM, JIS, EN H shape steel beam, BS Standard High Quality H BeamDIN,ASTM, JIS, EN H shape steel beam, BS Standard High Quality H BeamDIN,ASTM, JIS, EN H shape steel beam, BS Standard High Quality H Beam

H Steel Specifications-GB/T11263-2010
Type Model Weight-GB
(kg/m)		 Weight-JIS
(kg/m)		 Type Model Weight-GB
(kg/m)		 Weight-JIS
(kg/m)
HN 100*50*5*7 9.54 9.3 HW 100*100*6*8 17.2 16.9
125*60*6*8 13.3 - 125*125*6.5*9 23.8 23.6
150*75*5*7 14.3 14 150*150*7*10 31.9 31.1
175*90*5*8 18.2 18 175*175*7.5*11 40.3 40.4
198*99*4.5*7 18.5 17.8 200*200*8*12 50.5 49.9
200*100*5.5*8 21.7 20.9 250*250*9*14 72.4 71.8
248*124*5*8 25.8 25.1 300*300*10*15 94.5 93
250*125*6*9 29.7 29 350*350*12*19 137 134.9
298*149*5.5*8 32.6 32 400*400*13*21 172 171.7
300*150*6.5*9 37.3 36.7 HM 148*100*6*9 21.4 20.7
346*174*6*9 41.8 41.2 194*150*6*9 31.2 29.9
350*175*7*11 50 49.4 244*175*7*11 44.1 43.6
396*199*7*11 56.7 56.1 294*200*8*12 57.3 55.8
400*200*8*13 66 65.4 340*250*9*14 79.7 78.1
446*199*9*12 66.7 65.1 390*300*10*16 107 104.6
450*200*9*14 76.5 74.9 440*300*11*18 124 120.8
496*199*9*14 79.5 77.9 482*300*11*15 115 110.8
500*200*10*16 89.6 88.1 488*300*11*18 129 124.9
596*199*10*15 95.1 92.4 582*300*12*17 137 132.8
600*200*11*17 106 103.4   588*300*12*20 151 147
700*300*13*24 185 181.8 Materials
800*300*14*26 210 206.8 Q235, Q345, SS400
800*299*15*23 213 210
900*300*16*28 243 240



  1. Standard: GB, JIS , EN, ASTM A36, ASTM
  2. Grade: Q235B, Q345B, SS400, A36, S235JR, S275JR, S355JR
  3. Shape: H-shaped or H-channel
  4. Surface: Black, coating, galavnized
  5. Finish: Hot rolled
  6. Size: 100*100-900*300MM
  7. Length: 1000mm-12000mm
  8. Application: Petroleum & chemical industries, construction field, machinery and hardware fields, food processing and medical industry, high or low temperature resistant, electricity industries, etc.
  9. Packing: Standard export packages, custom suffocating free.
  10. Min order: 2ton
  11. Origin: China (Mainland)
  12. Note: can be made according to the customers' requirements.
