ZH-2B2 Automatic Auger Powder Filling Machine
Feature( Auger Powder Filling Machine)
This Auger Powder Filling Machine was designed for automatic can feeding, weighing, filling and failed packs detect & delete. The machine is suitable for packing powdery &grainy product, for instance, milk powder, monosodium glutamate, solid beverage, icing sugar, dextrose, feed, coffee, solid medicament, powdery & grainy additive, dye, etc.
Chinese /English touch screen and HMI, PLC control system, auger is drived by servo motor.
Equipped with automatic can/bottle feeding system, implement to the functions of no-can-no-filling.
Open-door hopper, a frame type machine be designed the humanization to easily wash. Reasonable mechanical structre, easy to change size parts and clean up.
The functions of over-weight warning, error message display and failed packs detecting & deleting, which never lt any reject to pass through, ensure the packing quality.
Max. 10 recipes can be saved for later using.
Have the functions of can support, vibration and dust extraction.
Technical Parameter( Auger Powder Filling Machine)
Filling Weight: 10-5000g
Weighing Range: 1-6000(with a resolution of 1g)
Packing Accuracy: ≤±0.3-1%(According to packing weight and product specs)
Packing Speed: 20-50 can/min
Power Supply/Total Power: 380/220V 50-60HZ 2kw
Use Tolerance/Air Pressure: 0.2m³/min 6-8kg/m²
Total Weight: 500kg
Overall Dimensions: 2450×1245×2300mm
Container Size: Cylindrical containers with a diameter of 50-180mm and a height of 50-350mm
