2.5mNm Load Torque High Speed Preicsion Motor,high-end Micro dc Motor
Negotiable
MOQ: 10 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Constar
Model Number:
2018RN51-4-7.4
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen or HK
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Diamater 16mm Length 40mm Graphite Brush High Precision Medical Coreless MotorNegotiableMOQ: 10 Pieces -
16*40mm Long Life Precision Graphite Brush Micro dc Coreless MotorUS$ 1 - 1,000MOQ: 10 Pieces
-
30mm 36V Micro Coreless DC MotorUS$ 10 - 100MOQ: 10 Pieces
-
22mm Electric 6 Volt dc MotorUS$ 1 - 40MOQ: 10 Pieces
-
8mm High Speed Micro dc Coreless Motor,toy Airplane MotorUS$ 1 - 10MOQ: 10 Pieces
Place of Origin
Guangdong, China
Brand Name
Constar
Model Number
2018RN51-4-7.4
Usage
Other, medical,health care and industrial automation., medical,health care and industrial automation.
Certification
CE, ROHS
Type
Micro Motor
Torque
2.5mNm
Construction
Other, precious metal commutation
Commutation
Brush
Protect Feature
Other, *
Speed(RPM)
19920rpm
Continuous Current(A)
899mA
Output Power
11.26W
Voltage(V)
7.4V
Efficiency
Other, *
2.5mNm load torque high speed preicsion motor,high-end micro dc motor
1.Applications: Audio and visual products, high-end toys, personal health care products and security equipment
2.Operating Environment: -10~+60°C; 15~90%RH
3.Characteristics:
The following are our standard products, we also provide customized products and service.
Series |
Performance Code |
Commutation Structure |
Dimension (mm) |
Voltage (V) |
Termanal resistence (Ω) |
No-load Speed (rpm) |
No-load Current (mA) |
Load Torque (mNm) |
Load Speed (rpm) |
Load Current (mA) |
2018RN51 |
2-7.4 |
Precious Metal |
Φ20*18 |
7.4 |
0.9 |
22000 |
85 |
2.2 |
20150 |
770 |
4-7.4 |
Precious Metal |
Φ20*18 |
7.4 |
1.2 |
23000 |
85 |
2.5 |
19920 |
899 |
4. Options: Lead wires length, shaft length, special coils, gearheads, encoder
