28V Electric Mini dc Brushless Servo Motor Suppliers

28V Electric Mini dc Brushless Servo Motor Suppliers thumbnail-1
28V Electric Mini dc Brushless Servo Motor Suppliers photo-1
Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Constar
Model Number:
EN2962ZW-1-28.0
Contact Supplier Request Quote Chat Now
Constar Micromotor Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen or HK
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Constar
Model Number EN2962ZW-1-28.0
Usage Other, medical instrument and industrial robot and so on, medical instrument and industrial robot and so on
Certification ROHS
Type Servo Motor
Torque 10.0mNm
Construction Other, precious metal commutation
Commutation Brushless
Protect Feature Other, *
Speed(RPM) 15100rpm
Continuous Current(A) 1.05A
Output Power 157.4W
Voltage(V) 28V
Efficiency Other, *

Specifications

1.brushless servo motor
2.Good quality;
3.Low noise
4.lead time 15-30 day

1.Applications:  Precision control fields like medical instrument,industrial robot and so on.



2.Operating Environment: - -10~+60°C;15~90%RH



3.Charateristics:

Series

Performance

Code

Dimension


(mm)

Motor Characteristics

Encoder Characteristics

voltage
(V)

Terminal resistance
(Ω)

Load torque

(mNm)

Load speed

(rpm)

Load current
(mA)

Number of channels

Counts per turn

Supply voltage

Max operating frequency

EN2962ZW

-1

φ29*62

28

1.16

10

15100

1050

2(3)

256--4096

5(3)

55--220





4.Options:  Lead wires length, shaft length, special coils, gearheads, bearing type, encoder channels, encoder counts per turn
