Stenter Heat Setting Drying Machine
US$ 80,000 - 300,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Automatic Grade:
Automatic
Place of Origin:
Jiangsu, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Stenter Heat Setting Finishing MachineUS$ 80,000 - 300,000MOQ: 1 Set -
Four Burners Gas Singeing MachineUS$ 60,000 - 100,000MOQ: 1 Set
-
Knitted Open Width Singeing MachineUS$ 60,000 - 120,000MOQ: 1 Set
-
Long Loop SteamerUS$ 100,000 - 300,000MOQ: 1 Set
-
Three Rollers Vertical CalenderUS$ 40,000 - 100,000MOQ: 1 Set
Condition
New
Automatic Grade
Automatic
Place of Origin
Jiangsu, China
Brand Name
HD
Model Number
HD180-360
Voltage
220v or 380v
Certification
CE marking
Warranty
13 months
After-sales Service Provided
Engineers available to service machinery overseas
HD180-360 Stenter heat setting drying machine
Detailed Product Description
This machine is used for stretching, drying and setting the cotton, polyester,and man-made fabric.
Technical Flow:
Plaint Entry -- 2-Roller Aslant Padder -- Obligate Photoelectric Weft Strangtener – Overfeeding -- Tridactylous Edge Spreader, Infrared Edge Sensor -- Pin or Clip or Combied Pin-Clip -- Stentering and Drying in the 8 Drying Chambers – Air-Jet Cooling -- Cooling Roller Cooling -- Swing Outlet
Main Techincal Parameter:
| NO. | ITEM | SPECIFICATIONS |
| 1 | Machine Type | Pin clip, Cloth clip or Combined pin and clip stenter |
| 2 | Machine Orientation | Left-hand or Right-hand (depend on you) |
| 3 | Machine Speed | 20-80m/minute |
| 4 | Machine Width | 1800~3600 |
| 5 | Amplitude Modulation Mode | The whole axle amplitude modulation. And you can set manual amplitude modulation in each drying chamber in addition according to your need. |
| 6 | Temperature | Maximum temperature is 220°C. The machine is setted automatic temperature controller. |
| 7 | Heating Method | oil, gas or electricity |
| 8 | Main Transmission | Control by the frequency motor with synchro so AV frequency convesion speed control synchronistically |
| 9 | Control Method | PLC order |
| 10 | Drying Quantity | 8 drying chambers ( 3m per chamber) |
| 11 | Recirculating Blower Quantity | 16 stand high temperature alternating motor, frequency conversion controlled |
| 12 | Pressure of Air Compression | 0.3Mpa |
| 13 | Machine Power | 160Kw (Start Power) |
