Specifications
HSHM300BF-D automatic stretch wrapping equipment1. work width: 300MM
2. work maturial: wooden veneer or decorative paper
HSHM300BF-D automatic stretch wrapping equipment
APPLICATIOINS:
The machine is especially used to overlay the wooden veneer or the decorative paper on decoration strips, aluminium and plastic material. Adopting high standard in gelatinizing.the machine could cover various angles, curve, concave and convexity. Slot wrap border etc, which suit for constrution maturial furniture, table,windows and door decorative strip and relative industry.
FEATURES:
1.The bottom wheels are all made by silicon rubber ,they are wearable and not sticky to the glue , it can be used long.
2.The electronic controlling components used famous brand products in China and they seldom break down.
3.The glue box and the glue plate will be heated at the same time and it can serve mass production without frequency adding glue to the machine.
TECHNICAL PARAMETER:
MODEL |
HSHM300BF-D |
HSHM450BF-D |
Max. working width |
300mm |
450mm |
Max. working thickness |
90mm |
120mm |
Shortest working length |
500mm |
500mm |
Conveying roller |
2 groups |
2 groups (or more) |
Conveying speed |
0-17mm/min |
0-17mm/min |
Conveying power |
0.37kw |
0.37kw |
Motor power |
1.1kw |
1.1kw |
Glue melting power |
4.5kw |
4.5kw |
Overall dimension |
3900*710*1800mm |
3900*950*1800mm |
Net weight |
1600kg |
2000kg |
Max. Loading diameter |
400mm |
400mm |
Any work-width available as customer:600mm/900mm/1200mm | ||
