Latest Technology Vertical Colloid Mill grinder machine
1)it has excellent function in superfine dispersing, emulsifing , homogenizing and complex etc,
after grinding, the particle size of materials processed will be reduced to 3-50 microns
2)the homogenelty more than 90% it is ideal equipment for superfine omplex processing of
corpuscles instead of such as homogenier, ball grinding mill. three-roller mill. agitator
etc. but several times more effcient than those above it may be used widely in various
3)processing industries such as food-stuff. pharmaceutical. chemical. cosmetic . light and
plastic etc
Machine’s Advantage:
Colloid mill works with shearing, grinding high-speed stirring .Grinding process occurs in relative movement between the two teeth with one revolving in high speed and another still, which makes the material between the teeth receive strong shearing and abrasion in addition to high frequency vibration and high speed swirl. The above forces effectively evenly disperse,emulsify, smash material.
Technical Pharameters:
Model |
Fineness um |
Output t/h |
Diameter of Scale mm |
Cooling Pipe mm |
Diameter of Inlet mm |
Diameter of Outlet mm |
Speed r/min |
Power kw |
Outline Dimension mm |
Weight kg |
JML-50 |
2-40 |
0.01-0.1 |
50 |
10 |
30 |
20 |
2800 |
1.5 |
270*500*700 |
55 |
JML-80 |
2-40 |
0.3-1 |
80 |
12 |
48 |
25 |
2800 |
3 |
335*570*920 |
85 |
|
||||||||||
JML-100 |
2-40 |
0.5-2 |
100 |
12 |
66 |
25 |
2800 |
5.5 |
680*370*900 |
115 |
JMF-100 |
2-40 |
0.5-2 |
100 |
12 |
66 |
25 |
2800 |
5.5/7.5 |
800*645*980 |
230 |
JMF-120 |
2-40 |
0.5-3 |
120 |
12 |
66 |
32 |
2800 |
7.5 |
800*645*980 |
240 |
Any more question, welcome contact us
