Simple Steel Slitting and Cut to Length Machine
US$ 25,000 - 30,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Tile Cutting Machine
Tile Type:
Colored Steel
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Ningbo China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Large Scale Hydraulic Slitting MachineUS$ 45,000 - 50,000MOQ: 1 Set -
SIMPLE Hydraulic Steel Slitting MachineUS$ 16,000 - 18,000MOQ: 1 Set
-
Hydraulic Slitting and Cutting MachineUS$ 16,000 - 18,000MOQ: 1 Set
-
New Hydraulic Slitting and Cut to Length MachineUS$ 16,000 - 18,000MOQ: 1 Set
-
Large Scale Hydraulic Slitting LineUS$ 45,000 - 50,000MOQ: 1 Set
Condition
New
Type
Tile Cutting Machine
Tile Type
Colored Steel
Use
Roof
Production Capacity
12~15m/min
Place of Origin
Zhejiang, China
Brand Name
WILLING
Model Number
WLFM 1250
Power(W)
6 Kw
Voltage
380V 3 phase 50 HZ or as customers' requirements
Dimension(L*W*H)
3000*1400*1500 mm
Weight
around 4500 KGS
Certification
CE & ISO9001:2008
Warranty
1 year
Specifications
1.High quality2.CE certificate
3.Best price
4.Comprehensive sevice
Simple slitting & cut to length machine with hydraulic un-coiler
1. Technical parameters
Material Spec |
Color-coated / Galvanized / Alu-zinc steel sheet |
Material yield stress |
235Mpa ~ 345Mpa |
| Coil thickness | 0.25 ~ 1.0mm |
| Coil width | 914/1000/1200/1220/1250mm |
| Line speed | 12 -15m/min |
| Main motor power | 3Kw |
| Hydraulic station power | 3Kw |
| Voltage | 380V 3phase 50 HZ or as customers' requirements |
| Un-coiler | 5 tons Hydraulic un-coiler with coil dia. 508mm |
| Slitting blades | Max. 9 sets blades |
| Max. slitting strips | 10 strips |
2. Material of main equipments
Roller Material |
High grade No. 45 forged steel, with digital-controlled procession, panted with hard chrome |
| Cutter blade: | Cr12 mould steel with quenched treatment, hardness HRC55-62 |
| Electric elements: |
Control system PLC panel, transducer and touch screen originally imported from Mitsubishi of Japan. Other elements from famous suppliers in China |
3. Standard equipments of machine
| 5 tons hydraulic un-coiler | 1 |
| Guiding equipment | 1 |
| Slitting equipment | 1 |
| Cutting equipment | 1 |
| Hdraulic stations | 2 |
| PLC control panel | 1 |
| Support tables | 2 |
| Spare parts | 1 wooden tooling box |
Send Inquiry to This Supplier
Business Type
Manufacturer, Trading Company
Year Established
2004
Factory Size
50,000-100,000 square meters
Total Employees
51 - 100 People
