2016 Laboratory Constant Climatic temperature humidity Test Chamber Price
Temperature and Humidity Testing Chamber is designed for testing the capability of heat-endurance, cold-endurance, dryness-endurance, and humidity-endurance, it is suitable for quality control of the industries of electron, electrical equipment, vehicle, metal, foodstuffs, chemistry, building materials, luggage, printing, packaging, etc.
| Environmental Temperature and Humidity Chamber/climate test chamber/machine/equipment | |||||||||||||||
| Secifications ( at +20ºC room temp. Or+25ºC water temp with empty load) | |||||||||||||||
| Model | KMH-R series | KMH-L series | KMH-S series | ||||||||||||
| 150R | 225R | 408R | 800R | 1000R | 150L | 225L | 408L | 800L | 1000L | 225S | 408S | 800S | 1000S | ||
| Temp. range | -20ºC~150ºC | -40 ºC~+150ºC | -70ºC~+150ºC | ||||||||||||
| Interior sizel | W(mm) | 600 | 700 | 700 | 1000 | 1000 | 600 | 700 | 700 | 1000 | 1000 | 700 | 700 | 1000 | 1000 |
| H(mm) | 600 | 700 | 750 | 1000 | 1000 | 600 | 700 | 750 | 1000 | 1000 | 700 | 750 | 1000 | 1000 | |
| D(mm) | 460 | 480 | 800 | 800 | 1000 | 460 | 480 | 800 | 800 | 1000 | 480 | 800 | 800 | 1000 | |
| Exterior size | W(mm) | 880 | 980 | 980 | 1280 | 1280 | 880 | 980 | 980 | 1280 | 1280 | 980 | 980 | 1280 | 1280 |
| H(mm) | 1730 | 1890 | 1940 | 2160 | 2160 | 1730 | 1890 | 1940 | 2160 | 2160 | 1890 | 1940 | 2160 | 2160 | |
| D(mm) | 1400 | 1460 | 1740 | 1750 | 1950 | 1400 | 1460 | 1740 | 1750 | 1950 | 1460 | 1740 | 1750 | 1950 | |
| Power(KW) | 5.8 | 6 | 7.5 | 12.8 | 12.8 | 7.5 | 7.5 | 8.5 | 14.5 | 14.5 | 9.5 | 10.6 | 18.5 | 18.5 | |
| Weight(KG) | 240 | 280 | 400 | 500 | 580 | 250 | 300 | 420 | 530 | 600 | 330 | 450 | 550 | 650 | |
| Humidity uniformity | ±3.0%R.H | ±5.0%R.H | ±3.0%R.H | ±5.0%R.H | ±3.0%R.H | ±5.0%R.H | |||||||||
| Heat up time | -20ºC~+100ºC,within 35 min | -40ºC~+100ºC, within 45 min | -70ºC~+100ºC,within 60 min | ||||||||||||
| Pull down time | +20ºC~-20ºC, within 45 min | +20ºC~-40ºC , within 60 min | +20ºC~-70ºC,within 80 min | ||||||||||||
| Standard accessories | Sight window*1, cable port(portΦ50mm)*1, shelves*2, chamber lamp*1, power cable *2m | ||||||||||||||
| Safety device (standard) | No fuse breaker, over pressureover heat and over current protection for compressor, | ||||||||||||||
| Over temp. protect, over load protect of blower, dry heat protection | |||||||||||||||
| Control System | Balanced Temperature & Humidity Control System | ||||||||||||||
| Refrigeration system | Air Cooled (Water Cooled Type is option) | ||||||||||||||
| Hermetic compressor,Single stage refrigeration system | |||||||||||||||
| CFC-Free refrigerant(HFC-507/HFC-23) | |||||||||||||||
| Controller | Panel:7-inch LCD Touch panel, Chinese or English display selectable | ||||||||||||||
| Operation model :Program or fix point running | |||||||||||||||
| Memory capacity :120programs,1200steps, | |||||||||||||||
| All repeat 999 cycles, part repeat 99 cycles | |||||||||||||||
| Humidity Range | 20~98%R.H | ||||||||||||||
| Temp. constancy | ±0.5ºC | ||||||||||||||
| Humidity constancy | ±2.5%R.H | ||||||||||||||
| Temp. uniformity | ±2.0ºC | ||||||||||||||
| Interior material | Stainless Steel Plate(SUS 304) | ||||||||||||||
| Exterior material | Baked Painting Steel Or Stainless steel(SUS304) | ||||||||||||||
| Insulation material | Rigid polyurethane Foam and Glass Fiber Wool | ||||||||||||||
| Ambient Temp. | +5ºC~+35ºC | ||||||||||||||
| Wiring method | AC 380±10%50Hz ,3 phase 4 wires +Ground Wires | ||||||||||||||
|
Note: 1. We reserve the right to change specifications without prior notice 2. Customized sizes and configurations available | |||||||||||||||
1.Environment chamber divided into three sections: the high temperature chamber, the
low temperature chamber and the testing chamber.
2.The color touch panel control system was made in Japan can display Chinese / English. The
big size liquid-crystal LCD has been adopted.
3.High formula memory capacity may be set to 120 patterns. The maximum cycle setting is
9999cycles. The maximum setting of each section is 999 Hrs 59 Mins.
4.Provide with RS-232C communication interface device, capable of controlling / editing/ recording
in the linkage with the computer and two set dynamic connection point and convenient application.
5.Both 2 zone and 3 zone shocks can be chosen.
6.All equipment is fully automatic, and all process are precisely controlled with P.L.C.’S.
7.Of any part of the malfunctions, the machine will automatically shuts down and a warning light switches on.
8.Machine can be shut down automatically in case of electrical power instabilities.
Compressor
Name: Bock Compressor
Brand: Bock(GEA)
Original: Germany
KOMEG use imported compressor from Germany with high efficiency low energy consumption, low noise.
Electronic components 1
Name: Electric cabinet
Brand: Schneider, DANFOSS, Omron, Panasonic
Original: GGermany, France, Japan
KOMEG use top brand electronics, with full range of protection include overheat of blower fan motor, earth leakage protection, load short circuit protection, over temperature protection, over pressure protection and so on.
Electronic components 2
Name: Oil seperator
Brand: EMERSON
Original: USA
Control System
Name: Controller
Brand: KOMEG/SAMWON
Original: China/South Korea
It can control temperature and humdity constantly such as thermo-hygrostat mounted on, termperature, humidity, respectively, by setting the PID values for each interval can be precisely controlled and easy control via PC or mobile is possible.
- High qualitty,Long life time and Competitive price
- Best after service:Professional R&D and technical team support,can make OEM & ODM order,and also can provide overall laboratory solutions,and good service.
- Strict quality control,more than 24hours befroe shipping and with 1year warrant
- With CE,ROHs,SGS and ISO certificates
- Fast response to your inquiry
Many other chambers for reference:
Environmental Climatic testing Chamber/ Temperature And Humidity Testing Chamber
Temperature/ humidity/ vibration three integrated Chamber
Rapid Temperature Change Chamber
3-zone/ 2-zone Thermal Shock Chamber
Walk-in Temperature And Humidity Chamber/ walk-in room
Precise Drying Test Chamber
Vacuum oven/ no oxidation oven
Burn-in Room
Salt spray Chamber
Vibration Testing Machine( mechanical and electromagnetic)
Aging test room
