Help CenterWC67Y-160T/4000 Hydraulic Press Braking Equipment
Related Products
-
Hydraulic Press Brake DiesUS$ 150 - 1,500MOQ: 1 Piece -
Press Brake Punch and DiesUS$ 220 - 5,200MOQ: 1 Piece
-
Hydraulic Press Brake ToolsUS$ 300 - 3,000MOQ: 1 Piece
-
Customize Design Press Brake MouldsUS$ 100 - 5,000MOQ: 1 Piece
-
T7 or 42CrMo Press Brake Punch and Die Tools 40T ~600TUS$ 5,000 - 20,000MOQ: 1 Set
Specifications
1.Press braking equipment2.ISO, SGS & CE certification
3.Professional manufacturer
4.Customize design
5.Easy operation
Details of WC67Y-160T/4000 hydraulic press braking equipment
INSTRUCTION:
The frame is steel-welded construction, vibration to eliminate stress, with high strength and good rigidity.
Mechanical stop nuts ensure stable and reliable positioning accuracy
Torque shaft is designed of rigidity with high solidness, assuring the synchronized movements of ram.
The ram's stroke and the back gauge's position can be speedily adjusted by motor and fine adjusted by handle.
Parameter of hydraulic press braking equipment
Model |
Nominal Pressure (kn) |
Length of table (mm) |
Distance Between Housing (mm) |
Throat Depth (mm) |
Stroke (mm) |
Open Hight (mm) |
Main Motor (kw) |
Dimensions (mm) |
Weight (t) |
40/2000 |
400 |
2000 |
1600 |
200 |
110 |
335 |
4 |
2545×1510×2050 |
3 |
40/2500 |
400 |
2500 |
2000 |
200 |
110 |
335 |
4 |
2950×1510×2080 |
3.5 |
63/2000 |
630 |
2000 |
1600 |
250 |
110 |
350 |
5.5 |
2555×1600×2130 |
3.8 |
63/2500 |
630 |
2500 |
2000 |
250 |
110 |
350 |
5.5 |
2960×1600×2180 |
4.2 |
63/3200 |
630 |
3200 |
2600 |
250 |
110 |
350 |
5.5 |
3740×1600×2230 |
5.2 |
100/2500 |
1000 |
2500 |
2000 |
350 |
150 |
400 |
7.5 |
2980×1650×2330 |
6.3 |
100/3200 |
1000 |
3200 |
2600 |
350 |
150 |
400 |
7.5 |
3740×1650×2355 |
7 |
100/4000 |
1000 |
4000 |
3200 |
350 |
150 |
400 |
7.5 |
4550×1650×2450 |
8.8 |
100/5000 |
1000 |
5000 |
4000 |
350 |
150 |
400 |
7.5 |
5100×1500×2650 |
11.8 |
125/2500 |
1250 |
2500 |
2000 |
350 |
150 |
410 |
7.5 |
3980×1650×2370 |
7.5 |
125/3200 |
1250 |
3200 |
2600 |
350 |
150 |
410 |
7.5 |
3750×1650×2450 |
8.2 |
125/4000 |
1250 |
4000 |
3200 |
350 |
150 |
410 |
7.5 |
4550×1650×2470 |
9 |
125/5000 |
1250 |
5000 |
4000 |
350 |
150 |
410 |
7.5 |
5100×1500×2795 |
11.5 |
125/6000 |
1250 |
6000 |
4500 |
350 |
150 |
410 |
7.5 |
6100×1500×2895 |
14 |
160/2500 |
1600 |
2500 |
2000 |
350 |
150 |
425 |
11 |
2980×1715×2410 |
8.5 |
160/3200 |
1600 |
3200 |
2550 |
350 |
150 |
425 |
11 |
3750×1715×2450 |
10 |
160/4000 |
1600 |
4000 |
3200 |
350 |
190 |
450 |
11 |
4550×1715×2730 |
12 |
160/5000 |
1600 |
5000 |
4000 |
350 |
190 |
450 |
11 |
5100×1570×2900 |
15.5 |
160/6000 |
1600 |
6000 |
4500 |
350 |
190 |
450 |
11 |
6100×1570×3010 |
18 |
200/3200 |
2000 |
3200 |
2600 |
350 |
240 |
460 |
11 |
3750×1815×2715 |
11 |
200/4000 |
2000 |
4000 |
3200 |
350 |
240 |
460 |
11 |
4550×1815×2850 |
13 |
200/5000 |
2000 |
5000 |
3800 |
350 |
240 |
460 |
11 |
5100×1715×3020 |
18.5 |
200/6000 |
2000 |
6000 |
4500 |
350 |
240 |
460 |
11 |
6100×1715×3120 |
21 |
250/3200 |
2500 |
3200 |
2600 |
400 |
240 |
525 |
11 |
3750×2010×2850 |
15.5 |
250/4000 |
2500 |
4000 |
3200 |
400 |
240 |
525 |
11 |
4550×2010×3010 |
17 |
250/5000 |
2500 |
5000 |
3800 |
400 |
240 |
525 |
11 |
5100×1890×3190 |
21.5 |
250/6000 |
2500 |
6000 |
4500 |
400 |
240 |
525 |
11 |
6100×1890×3350 |
28 |
300/3200 |
3000 |
3200 |
2600 |
400 |
250 |
545 |
15 |
3740×2100×3235 |
19.5 |
300/4000 |
3000 |
4000 |
3200 |
400 |
250 |
545 |
15 |
4340×2100×3300 |
22 |
300/5000 |
3000 |
5000 |
3800 |
400 |
250 |
545 |
15 |
5100×2100×3430 |
26 |
300/6000 |
3000 |
6000 |
4500 |
400 |
250 |
545 |
15 |
6100×2100×3490 |
29 |
