1.Running circumstance and conditions
Temperature (indoor): -5~ +40℃
Relative humidity: ≤90%
Input: 380V ±10%
Power frequency: 50 Hz ±1%
Compressed air: prepared by user
Pressure: 0.4~0.6Mpa
2. Workpiece specification
Diameter: φ60-φ320mm
Length: 6000mm-14000mm
Thickness: 3-5mm
Shape: conical tube/pyramid tube
Aper: ≤(3:100)
Material: Q235/Q345
3. Function description
During welding, the trolley takes the workpiece moving from small end to big end. The seam jointing is pressed by hydraulic system. Six pressure roller work synchronously.
4.Features
Auto jointing and auto welding are running synchronously.
Pressure rollers move synchronously.
Frequent inverter regulates steplessly.
It has the function of auto guiding.
It is equipped with emergency button.
5.Component
It is composed by the following parts.
Main frame
Trolley (moving workpiece)
Worktable with rails (trolley is put on it.)
Automatic submerged arc welding system
Soldering flux conveying system
End assistant unit
Seam guiding unit
Control system
