Automatic Beef Patty/ Burger Production Line
1. Process
Frozen meat cutting machine—Meat grinding machine—Meat mixing machine—Vertical hoisting machine—Meat patty forming machine-Quick Freezer—Packing machine
2. Detail specification
DQK-2000 frozen meat cutting machine
Introduction
It can cut frozen meat of -18℃--12℃. It can save some time and avoid of loss of nutrients and second pollution during melting. It is well-designed, best material and make sure the best quality of the machine .
Specification
Name |
Frozen meat cutting machine |
Feeding method |
Automatic |
Output power |
7.5kw |
Motor speed |
N=1000 r/min |
Knife speed |
41 times/min |
Knife distance |
220mm |
Material width |
460mm |
Capacity |
4-6t/h |
Dimension |
1500*720*1400mm |
Working table height |
1100mm |
B. JR-130 Meat grinding machine
It can grind the frozen meat in cube into meat in very small size.
It don't destroy the muscle fibers, small temperature rise which is be benefit for retaining freshness.
It is first step to meat beating;
Can grind frozen meat of -18℃.
Specification
Name |
Meat grinding machine |
Model |
JR-130 |
Capacity |
1t/h |
Power |
7.5kw |
Size |
1410*710*1130mm |
Weight |
220kg |
Holes |
3-16mm |
Temperature enhance after grinding |
≤2(℃) |
Meat mixing machine
Introduction:
It is double –shaft which can mix the meat from positive and negative to reach a high mixing speed and mix well.
The meat can be mixed well and no air bubble in the meat.
Made of stainless steel which is easy to be cleaned;
Specification
Name |
Meat mixing machine |
Model |
BX-400 |
Capacity |
400L |
Power |
4.5kw |
Size |
2000*730*1300mm |
Vertical hoisting machine
It is used to hoist the meat after grinding to the patty forming machine. It saves labor and of higher productivity.
Name |
Vertical hoisting machine |
Model |
T200 |
Hoisting weight |
200kg |
Power |
1.1kw |
Hoisting speed (m/min) |
3 |
Hoisting height (mm) |
1300-1900 |
Weight |
200kg |
Size |
1200*980*2650mm |
Movable cart
Name |
Movable cart |
Model |
200-300L |
Size |
690*650*650mm |
Material |
Sus304 |
Patty forming machine CXJ-600
Introduction
- 1. Full-automatic filling, forming, and outputing
- 2. It can be used to produce hamburger patty and chicken nuggets, fish patty, etc.
- 3. Hydraulic filling ensures the good shape and the consistent weight of the products.
- 4. The screw-driven conveyor ensures the minimum breakage of raw materials
- 5. It is made of stainless steel which meet requirement of HACCP.
mesh belt width |
600mm |
air pressure/water pressure |
6Bar/2Bar |
power |
15.12KW |
capacity |
800kg/h |
times |
15~60 times/min |
thickness |
6~40mm |
error |
≤1% |
diameter at maximum |
150mm(patty diameter) |
stowing pressure |
3~15Mpa |
overall dimension |
3170×1176×2636mm |
Finished products
Service guarantee: free maintenance for one year and technical services for life.
