Rotary Vibrating Sieve for Food Industries
US$ 1,800 - 3,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New, New
Type:
Other, Vibrating Sieve
Production Capacity:
99%
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin/Qingdao/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Vibration Sieve,vibration Filter,vibration ScreenUS$ 2,500 - 5,000MOQ: 1 Set -
Ultrasonic Vibrating Screen/vibrating Sieve/Shaking ScreenUS$ 4,000 - 8,000MOQ: 1 Set
-
Ultrasonic Vibrating Sieve For Pharmaceutical IndustriesUS$ 2,000 - 3,500MOQ: 1 Set
-
XCZP Direct Discharge Screen Rotary Vibrating Sieve for FlourUS$ 1,000 - 3,500MOQ: 1 Set
-
Flour Direct Double Motor Discharging Vibrating ScreenUS$ 1,200 - 3,500MOQ: 1 Set
Type
Other, Vibrating Sieve
Production Capacity
99%
Place of Origin
Henan, China
Brand Name
Xianchen
Model Number
XC-1000
Power(W)
0.75KW-1.5KW
Dimension(L*W*H)
According to the model
Weight
100kg-500kg
Certification
CE/ISO9001:2008
Warranty
1 Year
After-sales Service Provided
Engineers available to service machinery overseas
Voltage
110V-480V Design
Vibrating sieve
Rotary Vibrating Sieve for Food Industries
Product Description
Spin vibration sieve is a kind of high precision fine powder screening machine,the working principle is by upright motor as the source of vibration,the motor is installed at both ends of upper and lower eccentric weight,the motor rotation movement into horizontal, vertical, inclined three dimensional movement, then pass the movement to the screen surface. Adjust the phase angle of the upper and lower ends can change the direction of movement of material on the screen,vibration due to its operation principle, many companies also known as the "three dimensional vibrating screen points filter", according to the shape structure is part of the customer call for a circular screen, from the material divided into standard type rotary vibration sieve and ordinary type rotary vibration sieve, the part in standard type rotary vibration sieve contact with the material is 304 stainless steel material,the base is made of carbon steel,the general type of body for carbon steel material.
Dimensions
| Model | A | B | C | D | E | F | H | I | Single layer height | Double height | Three layer height |
| XC-600 | 560 | 460 | 120 | 600 | 130 | 95 | 450 | 410 | 750 | 860 | 1060 |
| XC-800 | 680 | 580 | 200 | 800 | 150 | 100 | 550 | 460 | 840 | 980 | 1120 |
| XC-1000 | 800 | 700 | 200 | 970 | 150 | 120 | 680 | 460 | 840 | 980 | 1120 |
| XC-1200 | 980 | 860 | 250 | 1170 | 180 | 140 | 790 | 580 | 1010 | 1150 | 1290 |
| XC-1500 | 1180 | 1060 | 280 | 1470 | 200 | 170 | 930 | 580 | 1060 | 1220 | 1380 |
| XC-1800 | 1490 | 1350 | 320 | 1770 | 200 | 180 | 1090 | 580 | 1220 | 1390 | 1560 |
Rotary vibrating screen pecifications
vibrating sieve details
Xinxiang Xianchen Vibration Machinery Co,. Ltd ,which is established in the year of 2009, located in China biggest machinery manufacture base Henan province, is a professional vibration machinery manufactures which specializes in the production of sieving equipments, conveying equipments, crushing equipments and feeding equipments as well as relevant parts. we committed to solve all kinds of sieving problem.
Our tenet: "market oriented, technology based, quality of survival, innovation and development ".We have passed ISO9001:2008 certification. Under the guide of international quality management system, our products have won not only good reputation in china but also applauses by foreign clients like United States, Germany, Turkey, Indonesia and so on.
vibration sievevibration sievevibration sievevibration sievevibration sieve sievevibration Our tenet: "market oriented, technology based, quality of survival, innovation and development ".We have passed ISO9001:2008 certification. Under the guide of international quality management system, our products have won not only good reputation in china but also applauses by foreign clients like United States, Germany, Turkey, Indonesia and so on.
Application
.Chemical industry: resin, coatings, industrial medicine,cosmetics, paint, Chinese medicine powder and so on. vibration sieve vibration sievevibration sievevibration sievevibration sieve vibration sieve
.The food industry: sugar, starch, salt, Rice noodles, milk powder, Soybean Milk, egg powder, soy sauce, juice and so on. vibration sieve vibration sieve vibration sieve vibration sieve vibration sieve
.The metal, mining and Metallurgy: aluminum powder, lead powder, copper powder ,mineral,alloy powder, electrode powder, manganese dioxide, electrolytic copper powder, electromagnetic materials,abrasive powder, refractory material, kaolin, lime, alumina, ground limestone,quartz sand and so on.
.Pollution treatment: waste oil, waste water, dyeing wastewater, additives, activated carbon and so on.
Features of rotary vibrating screen
The efficiency is high, the design is exquisite and durable, any fine kind, the mucus can be screened.
Easy to change net, easy to operate, easy to clean. vibration sieve vibration sieve vibration sieve
The mesh is not blocked, the powder can not fly, can screen to 500 mesh or 0.028mm.
Impurity coarse material automatic discharge, can continuous operation.
Unique network frame design, the screen was used for a long time, changing the net fast, only 3-5 minutes.
Small size, space saving, easy to move. vibration sieve vibration sieve vibration sieve vibration sieve
Screen up to five layers. vibration sieve vibration sieve vibration sieve vibration sieve vibration sieve
Easy to change net, easy to operate, easy to clean. vibration sieve vibration sieve vibration sieve
The mesh is not blocked, the powder can not fly, can screen to 500 mesh or 0.028mm.
Impurity coarse material automatic discharge, can continuous operation.
Unique network frame design, the screen was used for a long time, changing the net fast, only 3-5 minutes.
Small size, space saving, easy to move. vibration sieve vibration sieve vibration sieve vibration sieve
Screen up to five layers. vibration sieve vibration sieve vibration sieve vibration sieve vibration sieve
Workshop Process
Exhibition & Customers
Packaging & Shipping
FQA
*What's the MOQ?
1 sets is ok.
*What's the Payment?
L/C, T/T(30% as deposit, just pay remained 70% before shipping).
*How to pack it?
In normal, we packed it by wooden case.
And we accept your requirements.
*When will you shipping it after payment?
We will shipping it in 15-20 working days.
Waiting for your inquiry!
