Specifications
Baby Diaper Packing Machine1- Engineers available to servive machinery overseas
2- Customized machine is available
Company Information -- Baby Diaper Packing Machine
1- Anhui Yuanhong Machinery Automation Co.,Ltd is a high and new technology enterprise
which specialized in R&D and manufacture automatic packaging machine since 1995.
2- Specialized in 1kg-50kg powder & granule automatic bag packaging machine, secondary
packaging machine (small bags into big bag), bags/battles into box line Robot Palletizer,
automatic packing and packaging line, bag-sewing machine.
WELCOME TO VISIT OUR COMPANY !!!
Application -- Baby Diaper Packing Machine
1- The unit is the latest development of the new packaging machine, mainly to complete the
transfer over packed bags, change the horizontal to vertical placement, and then shaping,
M side down, and finally sewing the process of delivery.
2- Realized the bag from the horizontal to vertical and then automatically sewing process
3- Replaced the manual handling, manual sewing process, saving manpower, material and
financial resources invested to achieve fully automated packaging.
4- The device can be widely used in baby products, plastic products and other industries,
the level of bagging the completion of the preferred vertical sewing machines
5- Equipment basically consists of the horizontal conveyor, rotating section, reshaping section,
gusseting section, sewing section, sewing section,end product conveyor and storing section etc
6- Production process: end woven bag products ---horizontal conveyor--conveyor rotating mechanism
(the bags down vertically from the horizontal) --- M edge shaping machine and transported back ---
Automatic bag sewing machine product output
Samples -- Baby Diaper Packing Machine
Specifications -- Baby Diaper Packing Machine
MODEL |
GFS-1B |
Bag Size |
(1045-625mm) x width (442-350mm) x thickness (100-240mm) |
Packaging Materials |
paper bag,woven bag (lined with PP/PE film) |
Packing speed |
10-14 packages / min |
Compressed air |
0.5 ~ 0.7MPa, gas 0.9 m3/min |
Power |
3Kw 380V±10% 50Hz |
Advantage- Baby Diaper Packing Machine
1. To achieve bags from the horizontal to the standing of the process;
2. Automatic shaping function;
3. Do M side and transported to the sewing mechanism;
4. The touch screen control unit, operation, specifications switch is very convenient, safe and reliable;
5. Simple structure, stable performance, easy maintenance;
6. To meet a variety of bags specifications.
Optional Parts -- Baby Diaper Packing Machine
Packaging & Shipping -- Baby Diaper Packing Machine
Our Promise of Baby Diaper Packing Machine
Custom-made machine:
We have Great customized and design ability. Any required custom made machine can be
designed and manufactured for convenient operation and reasonable cost, making your
packaging system work smoothly.
Installation:
1- We provide videos and instruction manual to show the process of installation.
2- We provide training for installation for free in our factory.
3- We can send technician to buyer's factory to install the machine and provide training service.
After Sales Service:
1- One year quality warranty and free lifetime technique support.
2- Free spare parts would be supplied if machine broken within warranty period.
3- After the warranty period, the spare parts for replacement are offered based on certain charge.
Thank you for your inquiry and we will provide packaging solutions according to
your requirements immediately.
