Home > Packaging & Printing > Post-Press Equipment > Die Cutting Machine > Foam Cutting Machinery Vertical CNC Fast Wire Profile Cutting Machine(BYX)
Foam Cutting Machinery Vertical CNC Fast Wire Profile Cutting Machine(BYX)
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
This machine is mainly used for foam profile cutting
Place of Origin:
Jiangsu, China
Payment & Shipping
Payment Methods:
Port of Shipment:
NANJING SHANGHAI SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Mattress Foam Horizontal Cutter Machine (BPQ-WD)NegotiableMOQ: 1 Set -
Foam Contour Cutting Machine for PENegotiableMOQ: 1 Set
-
Foam Peeling Cutter Machine (BYQ)NegotiableMOQ: 1 Set
-
CNC Foam Contour Cutting Machine for Furniture Machine (BFXQ-2)NegotiableMOQ: 1 Set
-
Horizontal Foam Cutting Machine (BPQ)NegotiableMOQ: 1 Set
Condition
New
Application
This machine is mainly used for foam profile cutting
Place of Origin
Jiangsu, China
Brand Name
BCD
Model Number
BYX
Rated Power
10.74KW
No-Load Rotational Speed
0~25rpm
Max. Cutting Depth
30mm
Dimensions
BYX-1650 BYX-2150
Power(W)
10.74KW
Certification
CE\SGS
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
This machine is mainly used for foam profile cutting ,normal cutting shape is waviness.Foam Profile Cutting Machine
Foam profile cutting machine main application and performance:
This machine is mainly used for foam profile cutting ,normal cutting shape is waviness. The cut foam can be used for package of electronics ,precision instruments , car cushion ,healthy articles and other valuable objection etc..
Foam profile cutting machine technical Data:
| Model no. | BYX-1650 | BYX-2150 |
| Max. cutting width | W1650mm | W2150mm |
| Max. cutting depth | 30mm | 30mm |
| Profile roller speed | 0~25rpm | 0~25rpm |
| Total motor power | 10.74KW | 10.74KW |
| Cutting speed | 0~25M/min. | 0~25M/min. |
| Blade length | 8800mm | 9800mm |
| Machine weight | 2000Kg | 2500Kg |
| Machine dimension | L4200×W1250×H1550mm | L4700×W1250×H1550mm |
Basic info:
Description:
1. The primary source, short production cycle, product quality guaranteed.
2. We will provide a complete after-sales service, the machine packed in wooden cases.
