BLACK PLAIN WHERS DIN125
Negotiable
MOQ: 2 Tons (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
HY
Model Number:
DIN125
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai or chingtao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Shandong, China
Brand Name
HY
Model Number
DIN125
Specifications
1.DIN125 flat washer2.ISO9001:2008 CARTIFCATION.
3.Competitive price.
4.Quick delivery.
5.excellent in quality
DIN125 Flat Washer
DIN125 Flat Washer is main product of our company.
The information about DIN125 flat washer
1.material : carbon steel , low carbon steel, stainless steel(A2/304, A4/316)
2. surface : ZP/ YZP / HDG / PLAIN / BLACK
3. size : M3-52
4.type : DIN , SAE /USS, ISO, JIS , BS, NFE,etc.
5. price : reasonable
6.package :20-25KG,In bulk / In small box and then in carton and then into pallet 20'container
7 .usage :usually used in building and engineer
8. delivery : timely
9. high quality
10.the DIN125 flat washer's Tolerance:
| screw | inner diameter(mm) | out diameter(mm) | thickness (mm) | weight/M | ||||
| diameter | min | mum | min | mum | nominal | min | mum | (KG) |
| 5 | 5.3 | 5.48 | 10 | 9.64 | 1 | 1.1 | 0.9 | 0.443 |
| 6 | 6.4 | 6.62 | 12 | 11.57 | 1.6 | 1.8 | 1.4 | 1.02 |
| 7 | 7.4 | 7.62 | 14 | 13.57 | 1.6 | 1.8 | 1.4 | 1.39 |
| 8 | 8.4 | 8.62 | 16 | 15.57 | 1.6 | 1.8 | 1.4 | 1.83 |
| 10 | 10.5 | 10.77 | 20 | 19.48 | 2 | 2.2 | 1.8 | 3.57 |
| 12 | 13 | 13.27 | 24 | 23.48 | 2.5 | 2.7 | 2.3 | 6.27 |
| 14 | 15 | 15.27 | 28 | 27.48 | 2.5 | 2.7 | 2.3 | 8.62 |
| 16 | 17 | 17.27 | 30 | 29.48 | 3 | 3.3 | 2.7 | 11.3 |
| 18 | 19 | 19.33 | 34 | 33.38 | 3 | 3.3 | 2.7 | 14.7 |
| 20 | 21 | 21.33 | 37 | 36.38 | 3 | 3.3 | 2.7 | 17.2 |
