Help CenterDistance Parking Sensor
US$ 1 - 10
MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Type:
Other
Place of Origin:
Sichuan, China
Brand Name:
HTW, HTW
Payment & Shipping
Payment Methods:
Port of Shipment:
Chengdu
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Type
Other
Place of Origin
Sichuan, China
Brand Name
HTW, HTW
Model Number
EFR-40RS14B1, EFR-40RS14B1
Specifications
1. It has features of high sensitivity, high reliability and less power consumption.2. We can supply according to your demand
I. The Ultrasonic Sensor Applications:
1.Ultrasonic distance measuring.
2.Ultrasonic transmitting and receiving for the against and natural calamities against equipments.
II. Characteristics:
1.High sensitivity, high reliability, high stability.
2.High and low temperature resistance, humidity resistance, shock resistance, vibration resistance, etc.
III. Certificates:
ISO9001:2000/TS16949/RoHS
IV. Specifications:
- Nominal Frequency (kHz) 40±1
- Capacity (pf) 4400±20%
- Ring Time (ms) ≤1.2
- Sound Pressure Level (db) 105±5
- Sensitivity (db ) -73±5
- Resistance (Ω) 500
- Directivity (°) 110×60
Max.Input Voltage (Vp-p) 150 - Operating Temp.Range (oC) -30±80
- Storage Temp. (oC) -40±85
- Weight (g) 2.4
