EFR-40/48/58RS16C, Ultrasonic Parking Sensor
US$ 1 - 10
MOQ: 1 Piece
Key Specifications
Get Latest Price
Type:
Parking Sensor
Voltage:
DC 12V
Place of Origin:
Sichuan, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Chengdu
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Sell Sensitivity Parking Sensor, EFR-40RS15.5B1.US$ 1 - 10MOQ: 1000 Pieces -
Ultrasonic Sensor for Parking Aid SystemUS$ 0.5 - 1MOQ: 1 Piece
-
Touch Screen ComponentUS$ 0.6 - 0.8MOQ: 1000 Pieces
-
Parking Ultrasonic SensorUS$ 1 - 10MOQ: 1000 Pieces
-
Sell Ultrasonic Reverse SensorUS$ 1 - 10MOQ: 1000 Pieces
Type
Parking Sensor
Voltage
DC 12V
Place of Origin
Sichuan, China
Brand Name
HTW, HTW
Model Number
EFR-40/48/58RS16C, EFR-40/48/58RS16C
Specifications
1.Ultrasonic transducer is used for installation in parking system to detect obstacles.2.Certifications: ISO9001/TS16949/RoHS
I. Features of Ultrasonic Sensor EFR-40/48/58RS16C:
- Functions: transmitter and receiver.
- Terminal: pin
- Housing material: aluminum.
- Applications: range finders, burglar alarms, automatic door, remote control, ultrasonic distance meter.
- Features: High sensitivity, high reliability, less power consumption and waterproof.
II. Specifications:
Nominal Frequency (kHz) |
40±1 |
Capacity (pf) |
2000±15% |
Ring Down Time (ms) |
≤1.2 |
Sound Pressure Level (dB) |
105±5 |
Sensitivity (dB) |
-70±5 |
Resistance (Ω) |
500 |
Angle (°) |
90±5 |
Input Voltage (Vp-p) |
150 |
Operating Temp. Range (oC) |
-30~+80 |
Storage Temp. (oC) |
-40~+85 |
Weight (g) |
2.9 |
