1.Description:
long range wireless wifi 4G modem for family outdoor travel portable wifi
| LCD | 1.4 inch | TFT |
| Button | 1 Power KEY | Power ON/Power OFF |
| 1 Menu KEY | WPS KEY; SIM1/SIM2 swith KEY | |
| T-Flash card | Up to 32 GB | |
| WIFI | 802.11 b/g/n | MIMO supported |
| Battery | 2000mAh Lion |
7 hours working time 250 hours standing time |
| Port | ||
| 1 * Micro USB | MAX INPUT:5V--2A | |
| 1 * Standard USIM Slot | PLUS | |
| 1 * Micro SD | PLUS |
2.Main Pictures:
| Model | R86 | Pocket WiFi Router with Sim |
| Hardware Info | ||
| Processor | Qualcomm 28nm MDM9225M | |
| WiFi Chip | Atheros(Qualcomm) AR6004 | |
| TD-LTE | 3GPP/3GPP2 Release9,Category 4,up to 150M DL and 50M bps UL@20MHz bandwidth | |
| FDD LTE | 3GPP/3GPP2 Release9,Category4,up to 150M DL and 50M bps UL@20MHz bandwidth | |
| DC-HPSA+ | 3GPP/3GPP2 Release8, up to 42Mbps ,category 24,5.76M bps UL | |
| HPSA+ | 3GPP/3GPP2 Release7, up to 14.4Mbps ,category 10,5.76M bps UL | |
| HSPA | 3GPP/3GPP2 Release6, up to 7.2M bps DL,category 7/8,5.76M bps UL | |
| UMTS | 3GPP Release4, up to 384 Kbps DL and UL | |
| EDGE | 3GPP Release4, Multislot class 12, up to 237 Kbps | |
| GPRS | 3GPP Release4, Multislot class 10, up to 85.6Kbps | |
| Frequency | LTE TDD : 1.9(B39) 2.3(B40) 2.6(B38) GHz 2.6(B41) GHz | Power Class 3 |
| LTE FDD: B1(2100MHz) B3(1800MHz) B7(2600MHz) | Power Class 3 | |
| TD-SCDMA: 2.0(B34) 1.9(B39) GHz | ||
| UMTS: B1(2100MHz) B2(1900MHZ) B5(850MHZ) B8(900MHz) | Power Class 3 | |
| EDGE/GSM: B2(1900MHz) B3(1800MHz) B5(850MHz) B8(900MHz) | EDGE:Power Class E2 | |
| Peak rate | LTE FDD : DL/UL 150 / 50 Mbps (Category 3) | |
3.Model R86 Other informations you can reference belows:
| Software Info | ||
| OS | Win7, Windows XP, Vista, Mac OS | |
| Language | Chinese&English etc. | Multi Languages supported |
| Sharing | Up to 10 sharings | |
| Settings | ||
| SMS | Supported | |
| Contact Book | Supported | |
| APN Setting | Supported | |
| WIFI Settings | Supported | WiFi Repeater |
| Ethernet Settings | Supported | WAN & LAN |
| Device Settings | Supported | |
| Routing Settings | Supported | |
| Firewall Settings | Supported | |
| Certification | ||
| CE Granted | Up to customer | |
4.Packing&shipping :
| Size | 99mm * 59mm * 14mm | For reference,to be decided |
| Weight | 90g | |
| Standby Time | Up to 250 Hours | Finally decided by Battery |
| Working Time | Up to 7 Hours | Finally decided by Battery |
# use Carton pacakge
# Wireless Modem
# User manual
5.Warranty & maintenance:
We can provide 12 months maintenance warranties.
Items can be replaced during the first month or maintained for the first year.
6.Other hot 4G Products in our company :
Pls click the picutre which you want to get more info for our products:
8.Notice:
We are the professional OEM/ODM manufactory in this line and customized OEM packing,
logo printing as well different language web interface baced on your order.
We can guarantee to give you best professional free support .
9.Contact us :
Please contact me be free , also can add my skype : sentar002
10.Back to our home page ,click belows:
