PVC Ceiling Panel Machine/PVC Ceiling Extruder
US$ 55,000 - 75,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Profile
Plastic Processed:
PVC
Payment & Shipping
Payment Methods:
Port of Shipment:
QingDao Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
PVC Panel Profile Extrusion Line/PVC Wall Panel MachineUS$ 40,000 - 50,000MOQ: 1 Set -
PVC Cable Trunking Profile Extrusion Production LineUS$ 30,000 - 50,000MOQ: 1 Set
-
Co-extrusion Foamed WPC Profile Production Line/ WPC Extruder MachineryUS$ 30,000 - 100,000MOQ: 1 Set
-
Processing Type WPC Profile Making Machine/New Condition And Profile Application PVC Corner Bead Extrusion LineUS$ 30,000 - 50,000MOQ: 1 Set
-
PVC Wall Panel Production LineUS$ 55,000 - 75,000MOQ: 1 Set
Condition
New
Application
Profile
Plastic Processed
PVC
Screw Design
Double-screw
Automatic Grade
automatic
Place of Origin
Shandong, China
Brand Name
ASUN
Model Number
AS
Voltage
220/380
Power(W)
150kw
Weight
6t
Certification
CE
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
PVC Ceiling Panel Machine/PVC ceiling extruderpact good plastification,
2.high out long using life
3. CE approched
PVC Ceiling Panel Machine/PVC ceiling extruder
Process flow:
Automatic loader→SJSZ51;SJSZ65;SJSZ80 double-screw extruder→mould→vacuum calibration spraying platform→printer or hot stamping machine(option)→blade cutter→stacker
Other auxiliary equipment(optional):
| Name | Quantity |
| SRL-Z type of hot/cool mixer | 1set |
| Crusher | 1set |
| Miller | 1set |
| Air compressor | 1set |
Surface-treated machine(optional):
| Name | Quantity |
| Hot stamping machine or printer | 1set |
| UV oil coater | 1set |
| Levelling machine(three lights) | 1set |
| UV oven dryer | 1set |
Main technical parameter:
Model |
Product dimension (w×h)mm |
Extruder model |
output(kg/h) |
Max speed (m/min) |
Main motor power(KW) |
Length of line(m) |
SJYF-180 |
180×60 |
SJSZ51/105 |
80-100 |
6 |
22 |
23 |
SJYF-240 |
240×120 |
SJSZ65/132 |
140-180 |
4 |
37 |
27 |
SJYF-600 |
600×120 |
SJSZ80/156 |
300-400 |
6 |
55 |
30 |
