Help CenterCable Ladder Racks
Related Products
Specifications
cable ladder racks1.Have complete accessories.
2.Easy for installation.
3.Light weight
V cable ladder racks ICHNET stainless steel wire mesh cable tray (UL, CUL .CE.SGS)
WHY CHOSE VICHNET
1 Our Wire mesh cable tray can Guarantee 1O years.
2 Our wire mesh cable tray passed UL, CUL, CE test, the Only wire Mesh Cable Tray manufacturer who has UL certificate in China.
3 Google,Siemens, Microsoft, BT, China Telecom IDC wire mesh cable tray supplier with UL, CE certificated.
4 Our wire mesh cable tray have complete accessories,Can solve all kind of install solution
5 We draw down 8mm wire to 5mm to smooth and strengthen the wire.
6 There is no tolerance of our tray size and wire diameter.
7 Our zinc coating is non-toxic and 60μ up. It can be passed Rohs test.
8 Vichnet provides all solution for wire mesh cable tray systems, provide the technical guide movie.
ICHNET stainless steel wire mesh cable tray (UL, CUL .CE.SGS)
VI
CHNET stainless steel wire mesh cable tray (UL, CUL .CE.SGS)
VICHNET stainless steel wire mesh cable tray (UL, CUL .CE.SGS)
Vichnet is a telecommunication product manufacturer specialized in manufacturingstainless steel wire mesh cable tray (UL, CUL .CE.SGS).Our factory is located in the port city Ningbo.We have a professional team devoted to designing and producing reliable stainless steel wire mesh cable tray (UL, CUL .CE.SGS) that meet the needs of our global customers.
We are Google,Siemens, Microsoft, BT, China Telecom IDC stainless steel wire mesh cable tray (UL, CUL .CE.SGS)supplier with UL, CUL,CE ISO9001:2008 and GMC. certificated.
Our stainless steel wire mesh cable tray (UL, CUL .CE.SGS)passed Rohs, loading capacity, welding strength etc. tests.
Our stainless steel wire mesh cable tray (UL, CUL .CE.SGS) guarantee 10 years.
Material: VICHNET stainless steel wire mesh cable tray (UL, CUL .CE.SGS)
(stainless steel wire mesh cable tray (UL, CUL .CE.SGS))
Material |
Surface finishing |
Thickness of coating |
Application environment |
Q235 Steel |
Electro zinc plating |
>=12um |
Indoor |
Q235 Steel |
Hot dip galvanized |
>60um |
Indoor, Outdoor |
Q235 Steel |
Powder coating |
>60um |
Indoor, need colors |
SS304 |
acid washing |
N/A |
Indoor, Outdoor |
SS316 |
acid washing |
N/A |
Indoor, Outdoor, high corrosion occasions. |
SS316L |
acid washing |
N/A |
Indoor, Outdoor, high corrosion occasions. |
Dimensions: (Available for customized)
VICHNET stainless steel wire mesh cable tray (UL, CUL .CE.SGS)
cable ladder racks (UL, CUL .CE.SGS) dimensions are all internal size.
cable ladder racks (UL, CUL .CE.SGS) are constructed with a 50mm x 100mm, 50mm x 50mm, and 40mm x 40mm mesh grid.
Surface Finish:
Electro zinc plated cable ladder racks – for indoor use to BS EN 12329-2000, 12microns thick.
Powder coated cable ladder racks - for indoor use to JG/T3045-1998, between 60 and 100 microns thick
Hot Dipped Galvanized cable ladder racks – for outdoor use to BS EN 1461-1999, between 60 and 80 microns thick
Electrolytic Polishing cable ladder racks – for stainless steel use
Dimensions: (Available for customized)
cable ladder racks dimensions are all internal size.
cable ladder racks y are constructed with a 50mm x 100mm, 50mm x 50mm, and 40mm x 40mm mesh grid.
cable ladder racks Depth: 25mm, 50mm, 75mm, 100mm, 125mm, 150mm...
cable ladder racks Widths: 50~1000mm.
cable ladder racks Length: Maxiun 3000mm
cable ladder racks Wire Diameter: 3.5~ 6.0mm
Installation Notice: cable ladder racks
Bends, Risers, T Junctions, Crosses and Reducers can be made from cable ladder racks straight sections flexibly in project site.
cable ladder racks should be supported at a normally span 1.5m by trapeze, wall, floor or channel mounting methods (Maxium span is 2.5m).
cable ladder racks can be safely applied in places where the temperature ranges between -40°C and +150°C without any change to their characteristics.
Our Advance ( cable ladder racks )
1. Vichnet is a leading cable ladder racks manufacturer in China 2. Focus on producing cable ladder racks 3.ISO9001:2008/UL/CUL/CE, passed Rohs test 4. cable ladder racks EZ>12u, HDG>60u 5. Vichnet provides all solution for cable ladder racks systems, provide the technical guide movie. 6. Advance design team, OEM service accepted. 7. Siemens and GE specified cable ladder racks system supplier
Welcome to choose our high quality cable ladder racks
VICHNET stainless steel wire mesh cable tray (UL, CUL .CE.SGS)
