Specifications
fessional flexible silver color cable tray hangers approved UL/CUL/CE/ISO9001,Rohs.2.easy to install
3.low price
| specification | |
| Model Number | silver color cable tray hangers |
| Type | professional flexible silver color cable tray hangers |
| Brand Name | Vichnet |
| Place of Origin | China zhejiang |
| Material | Q235,SS304,SS316,SS316L |
| Surface Finish | Electro/hot dip galvanized,Powder coating,Acid washing polishing |
| Thickness of finishing | EZ>=12μm HDG>=60μm PC>=60μm |
| Color | Zinc |
| Welding Strength Tests | 23+/-2℃,50+/-5%RH |
| Salt Spray Tests | EZ>=96h HDG>=720h PC>=480h |
| OEM service | Available |
| Certificates | UL ,CUL ,CE, ISO9001,SGS, ROHS |
| Guarantee | 10 years |
| Safe work loading | BS EN 61537:2007 Cable Management Clause 10.4 |
| Port | Ningbo |
| Monthly output | 500K meters |
| Sample order | Available |
Different type of professional flexible silver color cable tray hangers and accessories
Product size: professional flexible silver color cable tray hangers
| Item Names | Height | Width | Length | Wire Diameter | Weight | |||
| CM Height-Width-Length-Diameter-Material | mm | inch | mm | inch | mm | inch | mm | kg/each |
| CM25-50-3000-3.5-SS316L | 25 | 1 | 50 | 2 | 3000 | 118 | 3.5 | 0.98 |
| CM50-50-3000-3.8-SS316L | 50 | 2 | 50 | 2 | 3000 | 118 | 3.8 | 1.84 |
| CM50-100-3000-4-SS316L | 50 | 2 | 100 | 4 | 3000 | 118 | 4 | 2.5 |
| CM75-150-3000-4.5-SS316L | 75 | 3 | 150 | 6 | 3000 | 118 | 4.5 | 4.52 |
| CM100-200-3000-4.8-SS316L | 100 | 4 | 200 | 8 | 3000 | 118 | 4.8 | 6.89 |
| CM125-300-3000-5-SS316L | 125 | 5 | 300 | 12 | 3000 | 118 | 5 | 9.37 |
Wire Mesh Cable Tray dimensions are all internal size.
CM25-200-3000-5-SS316L: professional flexible silver color cable tray hangers
| Dimensions | |
| Height(H):25mm-150mm... |
|
| Width(W):50mm-1000mm | |
| Length(L):300mm-3000mm | |
| Diameter(D):3.5mm-6.0mm | |
|
Installation Notice: 2014 latest flexible CE CUL UL certificated electric trunk >Bends, Risers, T Junctions, Crosses and Reducers can be made from professional flexible silver color cable tray hangersstraight sections flexible in project site. > professional flexible silver color cable tray hangerscan be safely applied in places where the temperature ranges between -40C and +150C without any change to their characteristics. >For security, professional flexible silver color cable tray hangerscan be made available with covers.
|
Our Certificates: professional flexible silver color cable tray hangers
| Ten Application Area: | |
| 1.data center | 6.sky-in solar energy |
| 2.railway industry | 7.food industry |
| 3.chemical industry and pharmacy | 8.equipment |
| 4.electrical industry | 9.robotics and automation |
| 5.energy production and distribution | nologies-such as wind power |
Project Reference: professional flexible silver color cable tray hangers
| SEVEN Advantages |
| 1.Vichnet is a leading certificated manufacturer in China. |
| 2.ISO9001:2008/UL/CUL/CE, passed ROHS and SGS tests. |
| 3.Vichnet provides all solution systems, provide the technical guide movie. |
| 4.Advance design team, OEM service accepted. |
| 5.Siemens and GE specified system supplier. |
| 6.Our product loading capacity is 27% stronger than traditional cable trays and cable ladder. |
| 7.Our product makes cables fast heat dispersion and prolong cable life. |
Packing and shipping: professional flexible silver color cable tray hangers
Our Company professional flexible silver color cable tray hangers
|
Vichnet is a telecommunication product manufacturer specialized in manufacturing professional flexible silver color cable tray hangers.Our factory is located in the port city Ningbo.We have a professional team devoted to designing and producing reliable professional flexible silver color cable tray hangersthat meet the needs of our global customers (over 100 countries). Vichnet professional flexible silver color cable tray hangershas approved UL,CUL,CE certificates and passed SGS,ROHS, loading capacity,welding strength etc tests.Our products guarantee 10 years. With GMC and ISO9001 certifications,vichnet becomes a qualified vender that supplies products for Siemens,Google,Microsoft,Coca Cola,IBM,Nsetle,China Telecom and Hua Wei etc. We are trying our best to win the satisfactions from customers. |
Our Service professional flexible silver color cable tray hangers
Welcome to choose our high quality Wire Mesh Cable Tray! More information
of our company please view our website:
