Help Center2014 Latest Flexible Aluminum Cable Tray
Related Products
-
2014 Latest Used in Various Occasion Rubber Cable TrayUS$ 1 - 5MOQ: 1 Piece -
Flexible Good Price Aluminum Cable TrayUS$ 1 - 5MOQ: 1 Piece
-
#500mesh 316l Stainless Steel Wire Mesh for E-cigUS$ 5 - 50MOQ: 1 Piece
-
300mm Certificated Professional Flexible Rubber Cable TrayUS$ 1 - 5MOQ: 1 Piece
-
2014 Latest Good Price Frp Cable TrayUS$ 1 - 5MOQ: 1 Piece
| specification | |
| Model Number | flexible aluminum cable tray |
| Type | 2014 latest flexible aluminum cable tray |
| Brand Name | Vichnet |
| Place of Origin | China zhejiang |
| Material | Q235,SS304,SS316,SS316L |
| Surface Finish | Electro/hot dip galvanized,Powder coating,Acid washing polishing |
| Thickness of finishing | EZ>=12μm HDG>=60μm PC>=60μm |
| Color | Zinc |
| Welding Strength Tests | 23+/-2℃,50+/-5%RH |
| Salt Spray Tests | EZ>=96h HDG>=720h PC>=480h |
| OEM service | Available |
| Certificates | UL ,CUL ,CE, ISO9001,SGS, ROHS |
| Guarantee | 10 years |
| Safe work loading | BS EN 61537:2007 Cable Management Clause 10.4 |
| Port | Ningbo |
| Monthly output | 500K meters |
| Sample order | Available |
Different type 2014 latest flexible aluminum cable trays and accessories
Product size: 2014 latest flexible aluminum cable tray
| Item Names | Height | Width | Length | Wire Diameter | Weight | |||
| CM Height-Width-Length-Diameter-Material | mm | inch | mm | inch | mm | inch | mm | kg/each |
| CM25-50-3000-3.5-SS316L | 25 | 1 | 50 | 2 | 3000 | 118 | 3.5 | 0.98 |
| CM50-50-3000-3.8-SS316L | 50 | 2 | 50 | 2 | 3000 | 118 | 3.8 | 1.84 |
| CM50-100-3000-4-SS316L | 50 | 2 | 100 | 4 | 3000 | 118 | 4 | 2.5 |
| CM75-150-3000-4.5-SS316L | 75 | 3 | 150 | 6 | 3000 | 118 | 4.5 | 4.52 |
| CM100-200-3000-4.8-SS316L | 100 | 4 | 200 | 8 | 3000 | 118 | 4.8 | 6.89 |
| CM125-300-3000-5-SS316L | 125 | 5 | 300 | 12 | 3000 | 118 | 5 | 9.37 |
CM25-200-3000-5-SS316L:
Wire Mesh Cable Tray dimensions are all internal size.
| Dimensions | |
| Height(H) | 25mm,50mm,75mm,100mm,125mm,150mm... |
| Width(W) | 50mm-1000mm |
| Length(L) | 300mm-3000mm |
| Diameter(D) | 3.5mm-6.0mm |
Installation Notice: of 2014 latest flexible aluminum cable tray
>Bends, Risers, T Junctions, Crosses and Reducers can be made from 2014 latest flexible aluminum cable tray straight sections flexible in project site.
>2014 latest flexible aluminum cable tray can be safely applied in places where the temperature ranges between -40C and +150C without any change to their characteristics.
>For security,2014 latest flexible aluminum cable tray can be made available with covers.
Our certificates:of 2014 latest flexible aluminum cable tray
Application: 2014 latest flexible aluminum cable tray
1.data center
2.railway industry
3.chemical industry and pharmacy
4.electrical industry
5.energy production and distribution
6.sky-in solar energy
7.food industry
8.equipment
9.robotics and automation
10. technologies-such as wind power
project reference: 2014 latest flexible aluminum cable tray
1. Vichnet is a leading 2014 latest flexible aluminum cable tray manufacturer in China.
2. Focus on producing 2014 latest flexible aluminum cable tray.
3. ISO9001:2008/UL/CUL/CE, passed ROHS and SGS tests.
4. Vichnet provides all solution for 2014 latest flexible aluminum cable tray systems, provide the technical guide movie.
5. Advance design team, OEM service accepted.
6. Siemens and GE specified 2014 latest flexible aluminum cable tray system supplier.
7.2014 latest flexible aluminum cable tray loading capacity is 27% stronger than traditional cable trays and cable ladder.
8.2014 latest flexible aluminum cable tray makes cables fast heat dispersion and prolong cable life.
Packing and shipping: 2014 latest flexible aluminum cable tray
Our company
Vichnet is a telecommunication product manufacturer specialized in manufacturing 2014 latest flexible aluminum cable tray.Our factory is located in the port city Ningbo.We have a professional team devoted to designing and producing reliable 2014 latest flexible aluminum cable tray that meet the needs of our global customers(over 100 countries).
Vichnet 2014 latest flexible aluminum cable tray has approved UL,CUL,CE certificates and passed SGS,ROHS, loading capacity,welding strength etc tests.Our products guarantee 10 years.
With GMC and ISO9001 certifications,vichnet becomes a qualified vender that supplies products for Siemens,Google,Microsoft,Coca Cola,IBM,Nsetle,China Telecom and
Hua Wei etc.
We are trying our best to win the satisfactions from customers.
Our service:
Welcome to choose our high quality Wire Mesh Cable Tray! More information of our company please view our website:
