Specifications
1.PVC Seal strip machine2.high speed: 10-20m/min
3.Low cost
4. daily output >10000m
5. Power 2kW
Plastic Machine for New automotive Seal Strip
PVC/SPVC/TPE/TPV/TPO/TPU Sealing Strip Machine:
Raw material:
PVC soft granule
Output:
30-40kg/h
Extruder:
single screw extruder
Process Flow:
PVC+Additive→Mixing→Loader→Single screw extruder→Cooling water tank→Haul-off→Winder
(Auxiliary machines:Crusher,Air compressor)
Feature of final product:
1. Good appearance:Smoth and beautiful
2. Good elasticity and anti-compressive deformation,resistance aging and ozone and chemical action
3. Good PVC material quality:Range the temperature from -20 °F - 150 °F (-29°C - 65.5°C)
4. Good Weather resistant
5. Good Fire and Water resistance
6. Suitable for Window and Door.
PVC Seal strip machine
Description:
Complete with door seals and production equipment, widely used in the automotive industry, home appliances and household products can also be applied to various needs of seal products industry
Equipment list:
1. SJ-65/25 single screw extruder 1 set
2. Mould 1 set
3. Vacuum trough 1 set
4. Hauling off 1 set
5. Winding machine 1 set
High performance single screw extruder and multi extrusion, and equipped with precision mold and auxiliary lines, it can process different automotive seal strip materials such as PVC/SPVC, TPE (TPV, TPO,TPU) and different types (hard and soft, soft hard combination, lined with alloy frame, metal fixture, tongue shape of car seal buckle, etc.); This production line is equipped with gluing machine, flocking machine, drying road etc, and can meet the requirement of automotive interior flocking strip production. Replacing the corresponding screw barrel, this production line can also be used to process the seal strip used on common mechanical device, with a wide range of application
.
For choosing proper machine and saving your time, please read these bellow guides carefully
1). What kinds of plastic machinery do you need ? Or what material do you want to process?
2). What capacity do you want? (tons per hour )
3).what is the max and min size of the finish prducts For example, the diameter of pipe(inch or mm); thickness of pipe wall(mm); width and thickness of sheet (mm)? If profile product, you’d better offer the picture of sample or drawing of sample.
4).what is the electric device you need ? Siemens,Omrn or domestic ?
5) When do you want the machine? (times for delivery)
6) Other requirements about the machine you want.
7) Please inform us your voltage, all we offer is 380V/3P/50HZ
Rely on us for a fast and competent response to all your service needs anywhere in the world. Whatever you need-from troubleshooting and training to spare parts-we’re on the job.
