Specifications
pvc door panel mahine plastic machinery1.Low energy consumption
2.Thickness: 30-40mm
3.Material: pvc+wpc power
PVC door panel machine production line
1. PVC – Wood Powder Foaming Board to replace traditional plastic and real wood board.
2. Board can be reused for minimum 30 times.
3. Board can be recycled even after use countless number of teams.
4. Photograph of Extrusion time enclosed.
5. Thickness: 30mm to 40 mm
6. Width: Up to 1220 mm
7. Manpower: 3-4 persons required to operate plant
8. Power Supply and Installation Power: 150 KW, all Siemens brand motor .
|
Description |
Parameter |
| Feed material | PVC+ assistant materials(also can add wood powder) |
| Product size | (width600-900mm,thickness30-50mm) |
| Production line speed | 0.8-1m/min |
| Max. output | 350-500kg/h |
| Outline size | 23×2.5×3 L×W×H(m),unsaturated |
| Weight | 16T |
| Total power | 150kw |
| Size | 30*2*2.5 m |
1)This wood plastic compound sheet production line uses either plastic compound or recycled plastic(PP/PE/PVC) and wood powder to produce a composite result.
2)Mainly used for decoration , floorings, furniture ,pallet and so on ..
3)The extruded product with this tooling has the advantages of plastic profile and the qualities of wood, such as good hardness, good rigidity, long service life, and good machine ability. The end product is resistant to the weather and is environmentally safe.
4)It is new material for two years in the world ,has big market in each country .Applications for this product include door thresholds and high impact areas.
The board width can be produced 1200mm , and thickness can be 30-40mm .
Delivery time: 50 days
Service:One year guarantee,long life maintain.
