1) safety
As the PVB glue is very toughness when the sandwich glass is broken as a result of external force ,the PVB glue coat
will absorb a great deal of the impact energy and make it die away quickly ,consequently the PVB sandwich coat very
difficult to be punctured and the glass can be maintained in the frame entirely and brings somewhat shading effect
even if it suffers from cracks under the impact .viewed from such aspect , the sandwich glass is real safety glass.
2)Sound insulation
Because PVB glue processes a highly strong blockage effect to sound waves , the sound waves obviously weakened
when passing the sandwich glass , reducing the noise interference suffered by work occasions or household living .
3)UV proofing
Having a highly good proofing effect to UV rays (the proofing ratio is higher than 90%)the valuable indoor furniture ,exhibits, arts and other artcles from fading as a result of influence of the UV rays.
4)application
With unique characteristics ,the sandwich glass is widely adopted in artcles and occasions such as buildings grating ,
aloft grounds ,high-rank curtain walls windows and doors, furniture ,show windows, aquarium.
Specification
The color of pvb
(1) Euro grey
(2)light brozen
(3)dark blue
(4)green
(5)ocean blue
(6)F-green
(7)blue-green
(8)milky white
(9) light yellow
(10)chinese red
(11)purplish red
(12)orange
(13)clear
the type of glass
(1)clear float glass
(2)tinted glass
(3) reflective glass
Size
3300*2250mm,3300*2134mm,3210*2250,2440*1830mm,2440*1530 etc
Thickness
6.38mm,6.76mm,8.38mm,8.76mm,10.38mm,10.76mm,12.38mm,16.76mm etc
Laminated Glass Performance Levels according to Thickness
Glass Characteristic |
Thickness (mm) |
UV Transmittance (%) |
LT (%) |
3+0.38+3mm Clear |
6.38mm |
5 |
89 |
6+0.38+6mm Clear |
12.38mm |
3 |
86 |
6+0.38+6mm Reflective |
12.38mm |
0.5 |
22 |
