Joney CCTV High Performance 8CH H.264 Surveillance DVR for Security CCTV DVR System

Joney CCTV High Performance 8CH H.264 Surveillance DVR for Security CCTV DVR System thumbnail-1
Joney CCTV High Performance 8CH H.264 Surveillance DVR for Security CCTV DVR System photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Joney
Model Number:
DVR-6316H
Contact Supplier Request Quote Chat Now
Shenzhen Joney Security Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Joney
Model Number DVR-6316H

Specifications

Dvr Surveillance H.264
1. 2 SATA, 2 USB, RS485, 1 RJ45(100M)
2. HDMI, VGA output up to 1080p
3. 16 ch audio in/1 out




Product Description


Joney  CCTV High performance 8CH H.264 Surveillance DVR for Security CCTV DVR System





Dvr Surveillance H.264



Joney CCTV High performance 8CH H.264 Surveillance DVR for Security CCTV DVR System





DVR Main Feature

Dvr Surveillance H.264
Overview

 16 channel video inputs
 16 ch audio in/1 out
All channel@ 960H realtime recording
HDMI, VGA output up to 1080p
8ch alarm in & 1ch relay out
16 sync realtime playback
2 SATA, 2 USB, RS485, 1 RJ45(100M)

> Up to 16 cameras with 1080p realtime preview
> H. 264 dual-stream video compression
> All channel 960H realtime recording
> HDMI / VGA / TV simultaneous video output
> All channel synchronous realtime playback, GRID interface & smart search
> Support 2 SATA HDD up to 4TB, 2 USB2.0
> Multiple network monitoring: Web viewer, CMS, Mobile phone (Iphone/Smart phone, Andriod, IPAD, Windows phone)





DVR  Parameters:



Dvr Surveillance H.264




System
Main Processor Embedded processor
Operating System Embedded LINUX
Video
Input 16  channel, BNC
Audio
Input 16 channel, RCA
Output 1 channel, RCA
Two-way Talk Reuse audio input/output channel 1
Display
Interface 1 HDMI, 1 VGA, 1 TV, BNC(1.0Vp-p, 75)
Resolution 1920×1080, 1280×1024, 1280×720, 1024×768, 800×600
Display Split 1/16
Privacy Masking 16 rectangular zones (each camera)
OSD Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Recording
Video/Audio Compression H.264 / G.711
Resolution 960H(1280X960)D1/4CIF(704×576/704×480) / CIF(352×288/352×240) / QCIF(176×144/176×120)
Record Rate Main Stream: D1
Bit Rate 48~4096Kb/s
Record Mode Manual, Schedule(Regular(Continuous), MD), Stop
Record Interval 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Video Detection& Alarm
Trigger Events Recording, PTZ, Tour, Video Push, Email, FTP, Spot, Buzzer & Screen tips
Video Detection Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank
Alarm Input 8 channel
Relay Output 1 channel
Playback & Backup
Sync Playback 16 channel
Search Mode Time/Date, MD & Exact search (accurate to second)
Playback Functions Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
Backup Mode USB Device / Network
Network
Ethernet RJ-45 port (10/100M)
Network Functions HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter
Max. User Access 20 users
Smart Phone iPhone, iPad, Android, Windows Phone
Storage
Internal HDD   2 SATA port, up to 4TB
Auxiliary Interface
USB Interface 2 ports (1 Rear), USB2.0
RS485 PTZ control
General
Power Supply DC12V/2A
Power Consumption 10W(without HDD)
Working Environment -10 ~+55°C / 10~90%RH / 86~106kpa
Dimension(W×D×H) 430x350x65mm/5KG(1.5U)
Weight 5KG(without HDD)
