Huawei XH621 V2 2 CPU Full Wide Sandy-Bridge Romley EP Server Node

Huawei XH621 V2 2 CPU Full Wide Sandy-Bridge Romley EP Server Node thumbnail-1
Huawei XH621 V2 2 CPU Full Wide Sandy-Bridge Romley EP Server Node photo-1
US$ 876 - 876 MOQ: 5 Units
Key Specifications
Get Latest Price
Products Status:
Stock
Type:
Rack
Max Memory Capacity:
Other, ≥ 64GB
Contact Supplier Request Quote Chat Now
ActForNet Technologies Inc.
Payment & Shipping
Payment Methods:
Port of Shipment:
HongKong
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Products Status Stock
Type Rack
Max Memory Capacity Other, ≥ 64GB
Max Processors 2
Processor Main Frequency 3.2GHz
Processor Type Intel Xeon
Brand Name Huawei
Model Number BC210RVSAB00
Place of Origin Guangdong, China

XH621 V2 2 CPU Full Wide Sandy-Bridge Romley EP Server Node

The XH621 V2 server node is a new-generation, full-width, 2-socket server node for the X6000. The XH621 V2 uses Intel® Xeon® E5-2600 or E5-2600 v2 series processors and supports eight 2.5-inch SAS/SATA HDDs or SSDs and 24 DDR3 DIMMs. It is ideal for High-Performance Computing (HPC) scenarios, such as cloud computing deployment and virtualization.



Features

Large memory capacity

  • The XH621 V2 supports 24 DDR3 DIMMs with a memory capacity of up to 768 GB, which allows more Virtual Machines (VMs) to run on a server.

Reliable internal storage

  • The XH621 V2 supports up to eight 2.5-inch SAS/SATA HDDs or SSDs and various RAID configurations.
  • The XH621 V2 uses a battery or supercapacitor for power-off protection.
  • The XH621 V2 uses TPM encryption to prevent unauthorized access.

Outstanding performance

  • The XH621 V2 supports up to two Intel® Xeon® E5-2600 or E5-2600 v2 series processors, whose 22-nm architecture builds on advanced manufacturing process technology to deliver higher performance.
  • The XH621 V2 supports four PCIe cards, providing a large memory capacity and storage capacity for various server applications.

Specification

Item XH621 V2
Form factor

Full-width server node
Number of processors

1 or 2
Processor

Intel® Xeon® E5-2600 or E5-2600 v2 series
Memory

24 DDR3 DIMMs
Core option: 4, 6, 8, 10, or 12
L3 cache: up to 30 MB
Internal storage

8 hot-swappable 2.5-inch SAS/SATA HDDs or SSDs
RAID support

RAID 0, 1, 10, 5, 50, 6, and 60
RAID cache: 512 MB or 1 GB
Power-off protection: BBU or supercapacitor
LOM network port

2 GE ports
Expansion slot

Up to 4 PCIe slots
USB port

5 (3 USB ports provided by a high-density connector, 1 internal USB port, and 1 built-in USB flash port)
Management

Built-in BMC, which supports IPMI, SOL, KVM over IP, and virtual media features
One 10/100 Mbit/s RJ45 management network port
Operating systems supported

Microsoft Windows Server
Red Hat Enterprise Linux
SUSE Linux Enterprise Server
Citrix XenServer
VMware
Operating temperature

5ºC to 35ºC
Certification

CCC, VCCI, CE, UL, FCC, RoHS
Dimensions

Height: 41 mm (1.61 in.)
Width: 423 mm (16.65 in.)
Depth: 540 mm (21.26 in.)
