Huawei TE40-720P30-P-02

Huawei TE40-720P30-P-02 thumbnail-1
Huawei TE40-720P30-P-02 photo-1
US$ 4,750 - 4,950 MOQ: 1 set
Key Specifications
Get Latest Price
Type:
Network Conference System, Video Conference System
Brand Name:
HUAWEI
Model Number:
TE40-720P30-P-02
Contact Supplier Request Quote Chat Now
ActForNet Technologies Inc.
Payment & Shipping
Payment Methods:
Port of Shipment:
Sunnyvale California USA
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Network Conference System, Video Conference System
Brand Name HUAWEI
Model Number TE40-720P30-P-02
Huawei Part#  2358349 Huawei Model#  TE40-720P30-P-02 HUAWEI TE40 HD codec 720P30, VPC600 HD camera(12x), VPM220 wired microphone array







Vendor Product Description Huawei Advantages
HUAWEI TE40 720P/1080P30/1080P60 codec,VPC600 1080P camera,VPM220 microphone/VPM220W Wireless microphone-Enter the configuration interface to configure quantities of each item.
CISCO SX20 HD Endpoint: 1080p60+WUXGA(content), Triple-View, 2 HD video in and 2 HD video out, 4 audio in and 2 audio out, 12X optical zoom 1080p60 dual stream;
Triple-View;
DP interface,XLR audio interface;
Wifi connection;
POLYCOM GROUP 500 HD Endpoint: 1080p60+1080p30(content), 3 HD video in and 2 HD video out, 4 audio in and 2 audio out, 12X optical zoom 1080p60 dual stream;
Triple-View;
DP interface,XLR audio interface;
Wifi connection





    Bring the people of your enterprise face-to-face across any distance

  • Built-in Wi-Fi connects to networks, presentation sources, microphones, and touch panels
  • VME + HP dual-core technology delivers superb HD-video with half the bandwidth of competing systems
  • Scalable Video Coding (SVC) and Huawei’s patented Super Error Correction (SEC) 3.0 provide excellent network adaptability and security while ensuring audiovisual quality even when the packet loss rate reaches 20%
  • Compatibility with a variety of protocols enables interoperability with Unified Communications (UC) systems, IP Multimedia Subsystems (IMSs), and other third-party systems



Huawei TE40-720P30-P-02





Specifications

TE40

TE50

TE60

Standards and Protocols

ITU-T H.323, IETF SIP, ITU-T H.239, and BFCP

ITU-T H.323, IETF SIP, ITU-T H.239, and BFCP

ITU-T H.323, IETF SIP, ITU-T H.239, and BFCP

Video Standards and Protocols

H.263, H.263+, H.264 BP, H.264 HP, and H.264 SVC

H.263, H.263+, H.264 BP, H.264 HP, and H.264 SVC

H.263, H.263+, H.264 BP, H.264 HP, and H.264 SVC

Video Resolution of People (using different network bandwidths)



  • 1080p60 using 1 Mbits/s (optional)
  • 1080p30 using 512 kbits/s (optional)
  • 1080i60 using 512 kbits/s (optional)
  • 720p50/60 using 512 kbits/s (optional)
  • 720p25/30 using 384 kbits/s



  • 1080p60 using 1 Mbits/s (optional)
  • 1080p30 using 512 kbits/s
  • 1080i60 using 512 kbits/s
  • 720p50/60 using 512 kbits/s
  • 720p25/30 using 384 kbits/s



  • 1080p60 using 1 Mbits/s (optional)
  • 1080p30 using 512 kbits/s
  • 1080i60 using 512 kbits/s
  • 720p50/60 using 512 kbits/s
  • 720p25/30 using 384 kbits/s

Dual Stream

Dual 1080p60 (optional); Dual 1080p30 (optional); Dual 720p30

Dual 1080p60 (optional); Dual 1080p30

Dual 1080p60 (optional); Dual 1080p30
Embedded MCU 6-way HD video sites + 3-way VoIP sites 6-way HD video sites + 3-way VoIP sites 9-way HD video sites + 3-way VoIP sites
Connected
Microphones		 Two VPM220 or two VPM220W Two VPM220 or two VPM220W Three VPM220 or three VPM220W

Video Inputs

1 x HD-VI/DVI, 1 x HDMI/DVI, and 1 x VGA/YPbPr

1 x HD-VI/DVI, 1 x HDMI/DVI, 1 x VGA/YPbPr, 1 x 3G-SDI, and 1 x CVBS

2 x HD-VI/DVI, 2 x DVI-I/HDMI/VGA/YPbPr

1 x HDMI/DVI, 1 x 3G-SDI, 1 x Display Port, and 1 x CVBS/S-VIDEO (DVI-I multiplex)

Video Outputs

2 x HDMI/DVI, 1 x VGA/YPbPr

2 x HDMI/DVI, 1 x VGA/YPbPr, 1 x 3G-SDI, 1 x CVBS

2 x HDMI/DVI, 2 x DVI-I/HDMI/VGA/YPbPr, 1 x 3G-SDI, 1 x CVBS/S-VIDEO (DVI-I multiplex)

Audio Inputs

1 x XLR, 2 x RCA, 1 x HDMI, 1 x HD-AI (microphone array/audio input device)

1 x XLR, 2 x RCA, 1 x 3.5 mm, 1 x HDMI, and 1 x HD-AI (microphone array/audio input device)

2 x XLR, 2 x RCA, 1 x HDMI, 1 x Display Port, and 1 x HD-AI (microphone array/audio input device)

Audio Outputs

4 x RCA, 2 x HDMI

4 x RCA, 2 x HDMI

4 x RCA, 2 x HDMI, 2 x DVI-I (DVI converted to HDMI)

Other Ports
  • IP: 10/100/1000 Base-T, 2 x RJ45
  • PSTN (#): 1 x RJ11
  • Wireless: built-in Wi-Fi
  • 2 x RS-232 COM, 2 x USB 2.0 Host
  • IP: 10/100/1000 Base-T, 2 x RJ45
  • PSTN (#): 1 x RJ11
  • Wireless: built-in Wi-Fi
  • 2 x RS-232 COM, 2 x USB 2.0 Host
  • 4E1 (optional): G.703, G.704, 4 x RJ45
  • PSTN (#): 1 x RJ11
  • IP: 10/100/1000 Base-T, 2 x RJ45
  • Wireless: built-in Wi-Fi
  • 2 x RS232 COM, 2 x USB 2.0 Host

Multiview

2-view

2-view

3-view
