GCS Draw Out Type Low Voltage Drawer Switch Cabinet Electric Cabinets
US$ 2,000 - 6,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Ghorit
Model Number:
GCS
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
KYN61-40.5kV Indoor Removable AC Metal-clad Switchgear CabinetUS$ 2,000 - 6,000MOQ: 1 Set -
MNS Indoor Low Voltage Standard Draw-out Type Switchgear CabinetUS$ 2,000 - 5,000MOQ: 1 Set
-
GCS Low Voltage Modified Withdrawable Type Switchgear Electrical CabinetUS$ 2,000 - 5,000MOQ: 1 Set
-
KYN28-12 Incoming and Outgoing Switchgear Board Panel CabinetUS$ 2,000 - 6,000MOQ: 1 Set
-
KYN28-12 Medium Voltage Switchgear Manufacturers 11kv Switchgear CabinetUS$ 2,000 - 6,000MOQ: 1 Set
Place of Origin
Zhejiang, China
Brand Name
Ghorit
Model Number
GCS
Specifications
GCS low voltage switch cabinet is suitable for power distribution systems of most industrial plants.
GCS low-voltage withdrawable switchgear is suitable for power distribution system of power plant in petroleum, chemical industry, building materials, metallurgy, textile, architecture and other industries. It is used in power distribution, motor central control, reactive power compensation devices for power system with 50(60)Hz frequency, rated voltage 380V(400, 660) and rated current 4000A or below.
Standards and specifications
IEC439-1 Low-voltage switchgear and control gear
GB7251.1-2005 Low-voltage complete set switch device
ZBK36001 Low-voltage withdrawable switchgear
Standards and specifications
IEC439-1 Low-voltage switchgear and control gear
GB7251.1-2005 Low-voltage complete set switch device
ZBK36001 Low-voltage withdrawable switchgear
Dimensions
| Height | 2200 | |||||||||
| Width | 400 | 600 | 800 | 1000 | ||||||
| Depth | 800 | 1000 | 800 | 1000 | 600 | 800 | 1000 | 600 | 800 | 1000 |
Main circuit rated voltage (v) |
AC380(400)(660) |
|
Auxiliary circuit rated voltage (v) |
AC220/380(400),DC110/220 |
|
Rated frequency (Hz) |
50(60) |
|
Rated insulation voltage(v) |
660(1000) |
|
Rated current(A) |
Horizontal busbar |
up to 4000 |
Vertical busbar(MCC) |
1000 |
|
Busbar rated short-time withstand current(kA/1s) |
50(80) |
|
Busbar rated peak withstand current(kA/0.1s) |
105(176) |
|
Power frequency test voltage (v /1min) |
Main circuit:2000 |
|
Auxiliary circuit:2000 | ||
Busbar |
three-phase four-line type |
A/B/C/PEN |
three-phase five-line type |
A/B/C/PEN/N |
|
Degree of protection |
IP30 IP40 |
|
