11kV cast-resin voltage transformer
Description
The types of outdoor voltage transformer are full cast- resin insulated used in outdoors. They are used for metering electric energy, voltage control and relay protection in the electricnon-useful ground neutral system up to 50Hz or 60Hz and 10kV. The transformers can beexe cuted according to the standards GB1207-2006 and IEC 60044-2.
Technical data
1 .The voltage transformers are in accordance with GB1207-2006 and IEC 60044-2 standards;
2. Power factor of load: COSφ =0.8(lagging);
3. Creep age distance: the product accords with the request of ιι class;
4. The other technical data see following table:
Type |
Rated voltage rated (V) |
Rated output (VA) |
Limit output (VA) |
Weight (kg) |
|
0.2 class |
0.5 class |
||||
JDZW-10 |
10000/220 |
25 |
50 |
300 |
22.5 |
10000/100/220 |
25 |
50 |
200 |
30 |
|
