LZZBJ4-35 35kV Dry Type Current Transformer

LZZBJ4-35 35kV Dry Type Current Transformer thumbnail-1
LZZBJ4-35 35kV Dry Type Current Transformer photo-1
US$ 200 - 500 MOQ: 10 Sets
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Ghorit
Model Number:
LZZBJ4-35, LZZBJ4-35
Contact Supplier Request Quote Chat Now
Ghorit Electrical Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo / Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name Ghorit
Model Number LZZBJ4-35, LZZBJ4-35
Usage Other, Current, Current
Phase Other, Three, Three
Coil Structure Other, Toroidal, Toroidal
Coil Number Autotransformer

Description

The series current transformer of the type LZZBJ4-35 and LZZBJ4-35A are casting resins and fully enclosed. They are use for metering electirc energy and current, relay prote­ction in the electrical system up to rated frequency 50Hz or 60Hz and rated voltage 35kV.



Technical data

1. Rated insulation level: 40.5/95/185 kV;

2. The load power factor: COS $= 0. 8 (lag);

3. Rated secondary current: 5 A or 1A

4. The product standard: GB1208-2006 and IEC 60044-1 <current transformer>;

5. Other technical parameters see table follow:





Rated primary current(A)

Accuracy classes combination and rated output(VA)

4-Second thermal current(kA)

(Idyn) Rated dynamic current(KA)

100,150,160,200

0.2/0.2/10P10/10P10 0.2/0.5/10P10/10P10 0.5/0.5/10P10/10P10 0.2/10P10/10P10/10P10 0.5/10P10/10P10/10P10 10P10/10P10/10P10/10P10

15/15/50/50 15/25/50/50 25/25/50/50 15/50/50/50 25/50/50/50 50/50/50/50

6011n

150 11n

300,40

0.2/0.2/10P10/10P10 0.2/0.5/10P10/10P10 0.5/0.5/10P10/10P10 0.2/10P10/10P10/10P10 0.5/10P10/10P10/10P10 10P10/10P10/10P10/10P10

15/15/50/50 15/25/50/50 25/25/50/50 15/50/50/50 25/50/50/50 50/50/50/50

15

40

600,800

0.2/0.2/10P10/10P10 0.2/0.5/10P10/10P10 0.5/0.5/10P10/10P10 0.2/10P10/10P10/10P10 0.5/10P10/10P10/10P10 10P10/10P10/10P10/10P10

15/15/50/50 15/25/50/50 25/25/50/50 15/50/50/50 25/50/50/50 50/50/50/50

20

50

1000,1200,1500

0.2/0.2/10P10/10P10 0.2/0.5/10P10/10P10 0.5/0.5/10P10/10P10 0.2/10P10/10P10/10P10 0.5/10P10/10P10/10P10 10P10/10P10/10P10/10P10

15/15/50/50 15/25/50/50 25/25/50/50 15/50/50/50 25/50/50/50 50/50/50/50

31.5

80

1500,1600

0.2/0.2/10P10/10P10 0.2/0.5/10P10/10P10 0.5/0.5/10P10/10P10 0.2/10P10/10P10/10P10 0.5/10P10/10P10/10P10 10P10/10P10/10P10/10P10

15/15/50/50 15/25/50/50 25/25/50/50 15/50/50/50 25/50/50/50 50/50/50/50

40

100





LZZBJ4-35 35kV dry type Current transformer
