JCZ5-7.2kV Vacuum Contactor 160A 250A 400A 630A Contactor 12KV Vacuum Contactor

Name: JCZ5-7.2kV Vacuum Contactor 160A 250A 400A 630A Contactor 12KV Vacuum Contactor
Brand: Ghorit
SKU: 128390025

JCZ5-7.2kV Vacuum Contactor 160A 250A 400A 630A Contactor 12KV Vacuum Contactor thumbnail-1

JCZ5-7.2kV Vacuum Contactor 160A 250A 400A 630A Contactor 12KV Vacuum Contactor photo-1

US$ 1,100 - 2,500 MOQ: 1 Set

Key Specifications

Get Latest Price

Brand Name:

Ghorit

Model Number:

JCZ5

Electricity Type:

Contact Supplier Request Quote Chat Now

Ghorit Electrical Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo/Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Brand Name Ghorit

Model Number JCZ5

Electricity Type AC

Number of Pole Other

Phase 3

Main Circuit Rating Voltage High Voltage

Main Circuit Rating Current 630a

VC5-12-160/250/400/630

Introduction

VC5-7.2,12/400,630 series vacuum contactor is used in an AC. 50-60 Hz electric power system, with rated working voltage is 7.2Kv and 12kV, and rated current of 400A,630A, for direct or romote on-off control and circuit-breaking control of the of the main load. It is especially suitable for the frequently operated electric control applications such as electric motors, transformer, etc. This series adopts integrated framework, before-and-after layout between the main circuit and controlling circuit, adopts electrical latch or machanical latch, and vacuum interrupter with ceramic shell.

Model

EVC	o	-	o	o	o	/	o	o	-	o	o
1	2		3	4	5			6		7	8

1. High-voltage AC vaccum contactor
2. Designed code
3. Rated voltage(kV)
4. Latching mode:J—machanical latch; D—electrical latch
5. G—high altitude; Y—movable type; None—basic type
6. Rated current(A)
7. Rated short-time withstand current(kA)
8. Vaccum shell materials: T—ceramic

Main technical specifications

Type form					EVC5-12
Raed work voltage			kV		12
Rated work current			A		160	250	400	630
Rated frequency			Hz		50/60
Rated thermal current			A		160	250	400	630
Rated making capacity			A		1600	2500	4000	6300
Rated breaking capacity			A		1280	2000	3200	5040
Limit breaking capacity			A		1600	2500	4000	6300
Limit breaking capacity			A/S		1600/4	2500/4	4000/4	6300/4
Operating cycle	Long time	Time/hr		300
	Short time	Time/hr		600
Method of operation					Non-Latched or Latched
Mechanical endurance			Ops.		1000000
Electrical endurance			Ops.		250000(AC-3)
					100000(AC-4)
Operation voltage			V		AC 120,220
Closing time			ms		≤200
Opening time			ms		≤160 (electric hold type)
					≤60 (mechanical hold type)
Power frequency withstand voltage	Main circuit	kV		42
	Secondary	kV		2.0
Auxiliary switch					3a,3b
