Specifications
Fruit Juice Making Machine1.fruit juice filler
pact structure
3.CE/ISO
Fruit Juice Making Machine
Products Introduction:
Usage:
RCGF series of Juice hot filling 3-in-1 unit is introduced advanced foreign technology such as washing, filling, capping technology. It is used in filling hot fruit juice, tea and other beverage, if you replace some parts, it can also be used in filling normal temperature filling.
Beverage Machinery-Equipment characteristics:
1. Using the wind sent access and move wheel in the bottle directly connected technology; canceled screw and conveyor chains, this enable the change of the bottle-shaped become easier.
2. Bottles transmission adopt clip bottleneck technology, bottle-shaped transform not need to adjust the equipment level, only change related the curved plate, wheel and nylon parts is enough..
3. The specially designed stainless steel bottle washing machine clip is solid and durable, no touch with the screw location of bottle mouth to avoid secondary pollution.
4. High-speed large gravity flow valve filling valve, filling fast, filling accurate and no liquid lose.
5. Spiraling decline when output bottle, transform bottle shape no need to adjust the height of conveyor chains.
6. Host adopt advanced PLC automatic control technology, the key electrical components from famous company such as Japan's Mitsubishi, France Schneider, OMRON.
7. Equipped with a constant temperature system, temperature controlled and circumfluenting automatically.
Beverage Machinery-Main technical parameters:
| Technical Data | ||||
| Model | RCGF14-12-4 | RCGF18-18-6 | RCGF24-24-8 | RCGF32-32-8 |
| The number of Washing, Filling, Capping | 14-12-4 | 18-18-6 | 24-24-8 | 32-32-8 |
| Producing capacity: The number of bottle(500ml)/hour |
3000-4000 | 5000-7000 | 8000-12000 | 12000-15000 |
| Applicable bottle specifications (mm) | H=170-320 | Φ=50-100 (330∼1500ml) |
||
| Pressure ( MPa) | 0.25-0.3 | |||
| General power (kw) | 1.5+0.37 | 2.2+0.37 | 3+0.45+0.25 | 4+0.45+0.25 |
| Overall dimension (mm) (L×W×H) | 2300×1680×2650 | 2500×1760×2650 | 3100×2100×2650 | 3800×2800×2650 |
| Weight(kg) | 2600 | 3500 | 4800 | 6500 |
If customer has other requirements,we will do as customer says.
Washing part
Filling part
