Help CenterVertical Machining Center With CE Verification
Related Products
-
Low Price 5-axis Machining Center VMC800 Cnc Horizontal Cnc Milling Machining CenterNegotiableMOQ: 1 Set -
VMC600/850B Cnc Machining CenterUS$ 15,000 - 40,000MOQ: 1 Set
-
Cnc Machine VMC600/850B Cnc Machining CenterUS$ 15,000 - 40,000MOQ: 1 Set
-
Cnc Grinding Machine VIK-5B Cnc Knife GrinderUS$ 170,000 - 180,000MOQ: 1 Set
-
4 Axis Tools Grinder VIK-4B Cnc Knife GrinderUS$ 20,000 - 80,000MOQ: 1 Set
|
Item Model |
VMC600 |
VMC850B |
Table travel(X,Y,Z) (mm) |
600×400×400 |
800×500×500 |
Table size (mm) |
750×420 |
1100×500 |
Number/Width/Distance of T-slot (mm) |
3-14-10 |
3-18-150 |
Distance from spindle nose to table surface(mm) |
128~528 |
150~650 |
Distance from spindle axis to column guideway (mm) |
480 |
560 |
Taper of spindle |
BT40 |
BT40 |
Spindle speed range (r/min) |
40~10000 |
40~6000 |
Spindle motor power (kw) |
(AC servo)7.5 |
(AC servo)7.5 |
Rapid feed speed(X,Y,Z) (m/min) |
48/48/60 |
24/24/18 |
Feed speed(X,Y,Z) (mm/min) |
2~10000 |
2.5~10000 |
Tool magazine capability (pcs) |
16 |
16 |
Max.dimension of tool (mm) |
Φ80X120 |
φ130×300 |
Max.weight of tool (kg) |
3.5 |
6 |
Positioning accuracy (mm) |
±0.005/300JIS |
±0.015 |
Repeat positioning accuracy (mm) |
±0.003JIS |
±0.01 |
Dimensions (Length×Width×Height) (mm) |
2000×1800×2200 |
2500×2260×2600 |
Weight (kg) |
3360 |
4750 |
Standard Configurations
1) CNC system: GSK25i servo system.
2) Spindle: Taiwan's high speed,precision spindle unit.
3) Tool magazine: Taiwan's armless library.
4) Ball screw: Taiwan's precision ball screw.
5) protection: full outer stainless steel inner defense and protection.
Optional:
1) KND-2000M,(HUAZHONG) HNC-21M,(JAPAN )FANUC 0i mate MD,828D
KND-2000M,HNC-21M,FANUC 0i mate MD or Siemens 828D.
2) CNC fourth axis.
3) Automatic chip removal system.
